Chapter 2: Jumpers and Connectors

Internal USB 2.0 Connectors

Connector type: 2x5 10-pin header
Connector location: USB56 and USB78
2
1 9
Pin Definition
1 +5V
3 S_USB_PN
5 S_USB_PP
7 GND
9 GND
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 GND
4 GND
6 S_USB_PP
8 S_USB_PN
10 +5V

Digital I/O Connector

Connector type: 2x5 10-pin header
Connector location: DIO
2 10
1 9
Pin Definition
1 DIO_I#1
3 DIO_P#3
5 DIO_O#1
7 DIO_O#3
9 +5V
15
Pin Definition
2 DIO_I#2
4 DIO_I#4
6 DIO_O#2
8 DIO_O#4
10 GND
