Display Information
NOTE. If you set a PICT display for additional tiles, each one affords independent control of the CC setup. You can turn it
on for one tile and leave it off for another, or you can set it to display differently from one tile to another. Conversely, CC
configuration set in the CONFIG menu applies globally to all tiles set to PICT.
NOTE. To set the global configuration for CC decoding, use the Aux Data Settings submenu of the CONFIG menu. You
can set the CC transport type, services in pop-up, and other global parameters. See To Monitor Closed Captioning in the
WVR6100, WVR7000, and WVR7100 Quick Start User Manual for more information.
When monitoring to ensure that branding or other elements do not overlay essential text or video action, use the PICT
menu to select a Safe Action and Safe Title graticule. The Safe Action Area is the maximum image area within which all
significant action should be contained, and the Safe Title Area is the maximum image area within which all significant titles
should be contained. You can select standard or custom safe area graticules.
To display safe area graticules overlaid on the display, use the menu to switch up to four Safe Area graticules settings to
ON.
NOTE. Select and/or define these graticules globally in the Graticules submenu of the CONFIG menu. You can set the
Safe Graticule Standard and define dimensions and offsets for custom Safe Graticules. See To Monitor for Safe Area
Compliance in the WVR6100, WVR7000, and WVR7100 Quick Start User Manual for more information.

Audio Display

Pressing the AUDIO button brings up the Audio Display. The Audio display provides level meters and a phase display for
monitoring audio signals. The Audio display always shows the level meters and correlation meters. When you choose to
display the phase plot (also known as Lissajous), the left portion of the Audio tile displays the level meters and the right
portion the Phase display. If the Dolby Digital (option DD) or Dolby E (option DDE) option is installed, you can display
Surround Sound in the right part of the Audio Tile, instead of the phase plot. See the figure that follows.
