Network Settings

If your CGW-I device is connected to the network, the Network Settings
window lets you define its address so that you can communicate with it
remotely over TCP/IP.
Field
IP Address
Subnet Mask
Gateway IP Address
Port

Reading Current Parameters

To download all configuration parameters from the connected CGW-I,
select: Communication
parameters.
Notes:
You must be connected to the device to read parameters. A password must be entered
before you can read parameters for the first time (default=1234) during a connection to a
specific CGW-I device. It is recommended that you change the password.
A gray bar will show the loading progress, followed by a message indicating
whether the action was successful or not. If it was, the different CGW-I
Manager screens now display all the current parameters of the connected
CGW-I.

Sending Current Parameters

You can make changes to the parameters offline, without being connected
to the device, but they will not be uploaded until you are connected. If you
are connected and click the Apply button, any changes you have made on
the open screen are sent to the device if you are connected.
To upload the configuration parameters that you may have changed and are
currently displayed on the different CGW-I Manager screens, select:
Communication
Note:
You must be connected to the device to send parameters. A password must be entered
CGW-I Cellular Gateway BRI-GSM : Installation and Operation Manual
Parameter
IP Address of your device in the network
Subnet Mask of your device in the network
IP Address of the network gateway
Port used by your device
Read Parameters, then click OK to read the
Send Parameters.
25
