Status Bar

The Status bar at the bottom of the Main screen displays important
messages about the current screen or how to get further Help.

Help

CGW-I Manager comes with context sensitive Help which describes each
field and button.
• To view Help for a window, press the screen's Help button.
• To view Help for a specific field, select it and press the F1 button.
• To view the main Help window, select Help
From any specific Help page, clicking the Contents tab will also
display the main Help window.

Buttons

The following table describes the different buttons found throughout the
various CGW-I Manager screens.
Button Function
OK Saves any changes you have made and then closes this window.
Apply Sends the changes made on this window to your device, but without
closing the window. If this is the first time you are sending parameters
to your device since login, a password is required.
Cancel Closes this window.
Close Closes this window and retains the changes you have made.
Help Displays all Help topics.

File Menu

The following table describes the different File menu options.
Button
New
Open
Save
Save As
Page Setup
CGW-I Cellular Gateway BRI-GSM : Installation and Operation Manual
Function
Creates a new configuration file, based on the default
parameters.
Toolbar shortcut: New button.
Opens an existing configuration file.
Toolbar shortcut: Open button.
Saves the current configuration file.
Toolbar shortcut: Save button.
Saves the current configuration file with a different name and/or
in a different directory.
Defines the printer paper setup.
Toolbar shortcut: Print button.
Help Topics.
19
