LCD Messages
No Name NoSig
No Num. NoSig
Calling -XXX
Ring At Dst –XXX
Ringing –XXX
Connected -XXX
Disconnecting –XXX
Busy -XXX
Drawer Open
ISDN Error
No Sync
ISDN Error
Interface Failure
ISDN Error
No Link
Error: Pin Code
Error: Puk Code
CGW-I Cellular Gateway BRI-GSM : Installation and Operation Manual
Description
If there is no signal and the name of the
operator is not available.
No Name is displayed when the Name value
is selected in LCD Operator Display (see
page 29).
If there is no signal and the number of the
operator is not available.
No Number is displayed when the Number
value is selected in LCD Operator Display
(see page 29).
When an outgoing call is being made,
Calling and the 2-3 digit signal level is
displayed.
When an outgoing call is ringing at the
destination number, Ring At Dst and the 2-3
digit signal level are displayed.
When an incoming call is ringing, Ringing
and the 2-3 digit signal level are displayed.
When a call is connected, Connect and the
2-3 digit signal level are displayed.
When a call is being disconnected,
Disconnecting and the 2-3 digit signal level
are displayed.
When an outgoing call is dialed and the
number is busy, Busy and the 2-3 digit signal
level are displayed.
The SIM drawer is open.
There is a synchronization error.
The is an error with the ISDN interface
communication.
There is no link to the PBX.
Displayed when you enter the incorrect SIM
code in the GUI.
When an incorrect PIN is entered and the
card is locked, you must call the network
operator to get the correct PUK code to
unlock the code.
Action
Check
antenna
location. See
Reception
Level, pg 48.
Check
antenna
location. See
Reception
Level, pg 48.
Close the
drawer
Check
physical cable
from NT
source to
Synch-In port.
Reset the
ISDN.
Check
physical cable
from NT
source to the
device.
Enter the
correct PIN or
disable the
PIN code.
Call your
network
operator to
get the PUK
code.
