Mount the SIP Call Button
Figure A-4
shows the maximum recommended wall cutout dimensions for mounting the SIP Call
Button.
Figure A-4. Maximum Recommended Wall Cutout Dimensions
0.38 [9.5]
ø0.19 [ø4.8]
(4 Places)
0.50 [12.8]
2.65 [67.3]
3.40 [86.4]
DIMENSIONS ARE IN INCHES [MILLIMETER]
Operations Guide
930801F
