1.2 Typical System Installation

The Session Initiation Protocol (SIP) SIP Call Button is a SIP endpoint designed to provide VoIP
phone connectivity in a tamper proof and secure package.
The following figures illustrate how the device can be installed as part of a VoIP phone system.
Figure 1-2. Typical Installation—Door Strike Intermediate Relay Module
Door Strike Intermediate
Door Strike
Relay Module
Figure 1-3. Typical Installation—Networked Door Strike Intermediate Relay Module
Networked Door Strike
Door Strike
Intermediate Relay Module
