View Trend Data - Extech Instruments GX900 User Manual

VIEW TREND DATA
Viewing data stored in the meter's memory is performed through the SAVE menu as
described below:
1. Press the F2 key (SAVE) and select menu item
MEMORY and Press the OK key.
2. Select menu item VIEW and Press the OK key.
3. Select menu item LOG and Press the OK key.
If there are previously stored records, press the F1 key
(PREV) to page through them or press the F2 key (NEXT) to
scroll in the opposite direction.
Press F4 (CLOSE) to return the meter to the normal
operating mode.
Press the F3 key (TREND) to display the recorded data in a
trend‐plot view. Press the F2 key (DELETE) to clear recorded
data.
Press the F3 key (SUMMARY) to get back to the data summary and Press F4 key
(CLOSE) to return to normal operating mode.
30
Extech Instruments
GX900-EU-EN V1.6 4/14
