Extech Instruments GX900 User Manual page 42

Function
Frequency
(electronic)
Frequency
(electrical)
Function
Duty Cycle
Function
RPM
Count
Clamp(DC)
Clamp(AC)
Function
Temperature
(type-K)
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176
Range
50Hz
500Hz
5kHz
50kHz
500kHz
5MHz
10MHz
Sensitivity: 2V RMS min. @ 20% to 80% duty cycle and <100kHz; 5V
RMS min @ 20% to 80% duty cycle and >100kHz.
40.00-10kHz
Sensitivity: 2V RMS
Range
0.1 to 99.90%
Pulse width: 100µs - 100ms, Frequency: 5Hz to 150kHz
Range
(0.01% + 10)
(0.5% + 10)
0.1-100mV/A
0.1-100mV/A
Range
-50 to 1000°C
-58 to 1832°F
TestEquipmentDepot.com
Resolution
0.001Hz
0.01Hz
0.0001kHz
0.001kHz
0.01kHz
0.0001MHz
0.001MHz
0.01 - 0.001kHz
Resolution
0.01%
Resolution
0.1A-0.0001A
0.1A-0.0001A
Resolution
0.1°C
0.1°F
42
Extech Instruments
Accuracy
±(0.01% + 10)
±(0.5% reading)
Accuracy
±(1.2% reading + 2
digits)
Accuracy
Clamp + 0.5%
Clamp + 0.5%
Accuracy
±(1.0% reading
+ 2.5°C)
±(1.0% reading
+ 4.5°F)
(Probe accuracy
not included)
GX900-EU-EN V1.6 4/14
