15 . Relay Test
This allows users to test relay on the display. Press "OK" button and start to
"Success" is displayed when the Relay Test is correct.
16 . Reactive Power
This allows users to change Reactive Power on the display.
Press "OK", then "input password" will be displayed, press "OK" again to input the password
(0001), press "Up" or "Down" to change the number, press "OK" to go to next digit."success"
is displayed when the Start Parameter is correct.
17.
Power Derate
This allows users to change Power Derate on the display.
Press "OK", then "input password" will be displayed, press "OK" again to input the password
(0001), press "Up" or "Down" to change the number, press "OK" to go to next digit."success"
is displayed when the Power Derate is correct.
18.
Reflux Power
This allows users to change Reflux Power on the display.
Press "OK", then "input password" will be displayed, press "OK" again to input the password
(0001), press "Up" or "Down" to change the number, press "OK" to go to next digit."success"
is displayed when the Reflux Power is correct.
19.
Autotest Fast
Step 1: During the normal operation of our SOLAR inverters, press "back" button (the
leftmost button) to enter the main menu interface.
Step 2:Press "Confirm" button (the rightmost button) to enter the "Enter Setting"
menu interface.
Step 3:Press "Down" button several times until "Autotest Fast" is shown on the screen.
1.Enter Setting
Up
Down
Step 4:Press "Confirm" button to start Auto Test:
19.Autotest Fast
Step 5:Then the Auto Test will start automatically, Press "down" to see the test results
Testing 59.S1...
Wait
All rights reserved C Zucchetti Centro Sistemi S.p.A.
test relay .
Press "OK"
1.Set Time
. . .
19.Autotest Fast
Test 59.S1 OK!
Press "Down" button to see the test results
59.S1:230V 183ms
Wait for another test
Testing 59.S2...
Wait
Test 59.S2 OK!
Press "Down button" to see the test results
59.S2:230V 100ms
Wait for another test
Testing 27.S1...
Wait
Test 27.S1 OK!
Press "Down" button to see the test results
27.S1:230V 384ms
Wait for another test
Testing 27.S2...
Wait
Test 27.S2 OK!
Press "Down" button to see the test results
27.S2:230V 188ms
Wait for another test
Testing 81>S1...
Wait
Test 81>S1 OK!
Press "Down" button to see the test results
81>S1:49.9Hz 83ms 81>S1:49.9Hz 83ms
Wait for another test
Testing 81>S2...
Wait
Test 81>S2 OK!
