max 15º
Minimum Installation distance for single inverter
Installation of multiple inverters
All rights reserved C Zucchetti Centro Sistemi S.p.A.
3.5 Moving the inverter
This topic describes how to move the
Step 1 Opening the packing, insert hands into the slots on both sides of the inverter and hold
the handles, as shown in Figure 3-3 and Figure 3-4.
Figure 3-3 Moving the inverter (1)
Figure 3-4 Moving the inverter (2)
Step 2 Lift the inverter from the packing case and move it to the installation position.
To prevent device damag and personal injury, keep balance when moving the
inverter because the inverter is heavy.
Do not put the inverter with its wiring terminals contacting the floor because
the power ports and signal ports are not designed to support the weight of the
inverter. Place the inverter horizontally.
When placing the inverter on the floor, put foam or paper under the inverter
Attention to protect its shell.
End
