Technical Specifications

SDI Video
Interface SMPTE ST259, ST292, ST424
Data Rate 270Mbps, 1.5Gbps, 3Gbps
Input/output Level 800mVp-p
Input/output Impedance 75 Ohms
Connector, Camera Unit BNC,
Connector, Base Unit BNC
Embedded Audio Supported Yes
Video Genlock (Reference)
Type Analog Black Burst, Tri-Level
Impedance 75 Ohms
Level 1Vp-p
Connector, Camera Unit Internal 68-pin
Connector, Base Unit BNC
Connector, Base Unit BNC
Embedded Audio Supported Yes
Analog Audio
Audio
Type Balanced Analog Line-Level
Level +4dBu nominal, +24dBu max.
Input Impedance > 10k ohms
Output Impedance 50 ohms
THD+N Better than 0.1%
Frequency Response +0.1 dB/-3dB, 20Hz to 20kHz
Connector, Camera Unit DB9
Connector, Base Unit DB25
24
Technical Specifications
Intercom Audio
Number of Channels 2
Interface 2-Wire or 4-Wire
Compatibility RTS, Clear-Com
Headset MIC Type Dynamic
Headset MIC Impedance 200 Ohms nominal
Level, 4-Wire +4dBu nominal, +24dBu max.
Level, 2-Wire -10dBu nominal
Connector, Headset XLR-5
Connector, Base Unit DB25
Camera Remote Control
RCP Camera Control (Remote)
Type JVC RCP (RS232)
Connector, Camera Unit Internal 68-pin
Connector, Base Unit 6 pin Mini-DIN
Ethernet
Ethernet
Data Rates 10/100/1000 Base-T
Connector RJ45 Cat5e
Tally / GPIO
Input type Short to GND or TTL Low to Activate
Output Type Relay Contact Closure (30V, 2A max)
Connector, Camera Unit DB15
Connector, Base Unit DB25
Timecode
Type SMPTE/EBU LTC
Inputs Unbalanced, 15Vp-p max
Outputs Unbalanced, 3Vp-p max
Connector, Camera Unit Internal
Connector, Base Unit BNC
