ComAp IG-NT Reference Manual page 303

position.
Analog input: LdCtrl:AnExI/E
Related FW 3.0
Description This functional input is used for requesting the mains import value externally by
an analog input. The setpoint
Analog input: PFCtrl:AnExBPF
Related FW 3.0
Description This functional input is used for requesting the gen-set cos phi factor externally
by an analog input. The setpoint
position.
The analog value is transformed to the requested cos phi factor following way:
A
NALOG VALUE
<60
60 .. 100
101 .. 120
Analog input: PFCtrl:AnExI/E
Related FW 3.0
Description This functional input is used for requesting the mains cos phi factor externally by
an analog input. The setpoint
position.
The analog value is transformed to the requested cos phi factor following way:
A
NALOG VALUE
<60
60 .. 100
101 .. 120
Analog input: LdCtrl:I/E-Pm
Related FW 3.0
Description This functional input is used for connecting of an external device, which measures
the active power imported from the mains. The device is connected to the
controller via an analog input (e.g. -20 .. 20mA). The setpoint
be set to the ANALOG INPUT position for this case.
Analog input: PFCtrl:I/E-Qm
Related FW 3.0
IGS-NT Combi, SW Version 3.0, ©ComAp – May 2013
IGS-NT-Combi-3.0 Reference Guide.PDF
Load ctrl PtM must be set to ANEXT IM/EX position.
PF ctrl PtM must be set to ANEXT BASEPF
COS PHI FACTOR
0.6L
0.6L .. 1.00
0.99C .. 0.80C
PF ctrl PtM must be set to ANEXT PF-IM/EX
COS PHI FACTOR
0.6L
0.6L .. 1.00
0.99C .. 0.80C
I/E-Pm meas must
