Value: AIN CU-1
Group Analog CU
Units configurable
Related FW 3.0
Description This is the value of the analog input 1 of the controller. Analog inputs are fully
configurable so the name and units depend on configuration. In the default
configuration the input is used for oil pressure measurement.
Value: AIN CU-2
Group Analog CU
Units configurable
Related FW 3.0
Description This is the value of the analog input 2 of the controller. Analog inputs are fully
configurable so the name and units depend on configuration. In the default
configuration the input is used for water temperature measurement.
Value: AIN CU-3
Group Analog CU
Units configurable
Related FW 3.0
Description This is the value of the analog input 3 of the controller. Analog inputs are fully
configurable so the name and units depend on configuration. In the default
configuration the input is used for fuel level measurement.
Value: AIN CU-4
Group Analog CU
Units configurable
Related FW 3.0
Description This is the value of the analog input 4 of the controller. Analog inputs are fully
configurable so the name and units depend on configuration. In the default
configuration the input is used for fuel level measurement.
Group: Bin inputs CU
Value: BIN
Group Bin inputs CU
Units -
Related FW 3.0
Description This is a bit array containing status of physical binary inputs of the controller. Bit0
represents BI1, bit1 represents BI2 etc..
N
OTE
All terminals display binary values in "human-readable" form - from left to right.
That means the bit 0 is displayed in the most left position. This is different from
common use in computer science, where binary values are displayed from right to
left.
