ComAp IG-NT Reference Manual page 152

Related FW 3.0
Description This setpoint adjusts the maximum allowed negative difference between a
particular cylinder temperature and average cylinder temperature at minimum
power level adjusted by setpoint PminCylDifEval. This setpoint is one of four
setpoints that define the allowed area of cylinder temperature differencies
depending on gen-set power. See the setpoint
Setpoint: Max+CylDifPnom
Group Engine protect
-32000 .. +32000 [°C]
Range [units]
Related FW 3.0
Description This setpoint adjusts the maximum allowed positive difference between a
particular cylinder temperature and average cylinder temperature at nominal
power. This setpoint is one of four setpoints that define the allowed area of
cylinder temperature differencies depending on gen-set power. See the setpoint
Max+CylDifPmin
Setpoint: Max-CylDifPnom
Group Engine protect
-32000 .. +32000 [°C]
Range [units]
Related FW 3.0
Description This setpoint adjusts the maximum allowed negative difference between a
particular cylinder temperature and average cylinder temperature at nominal
power. This setpoint is one of four setpoints that define the allowed area of
cylinder temperature differencies depending on gen-set power. See the setpoint
Max+CylDifPmin
Setpoint: PminCylDifEval
Group Engine protect
Range [units] 0.0 ..
Related FW 3.0
Description This setpoint adjusts the gen-set power level below which the cylinder
temperature difference protection is not evaluated. Learn more about this
protection in the description of the setpoint Max+CylDifPmin.
Setpoint: CylDifEvalDel
Group Engine protect
Range [units] 0 .. 600 [s]
Related FW 3.0
Description This setpoint adjusts the evaluation delay of the cylinder temperature difference
protection. Learn more about this protection in the description of the setpoint
Max+CylDifPmin.
IGS-NT Combi, SW Version 3.0, ©ComAp – May 2013
IGS-NT-Combi-3.0 Reference Guide.PDF
for more details.
for more details.
Nomin power [kW]
Max+CylDifPmin for more details.
