C3-540 CORIOmaster™
C3-510 CORIOmaster mini™
C3-503 CORIOmaster micro™
CORIOgrapher™ V2.5 and above
Quick Start Guide V2.20
Firmware version M404 and above
QSG-C3-5x0-V2.20
Jun 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C3-540 CORIOmaster and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tvone C3-540 CORIOmaster

  • Page 1 C3-540 CORIOmaster™ C3-510 CORIOmaster mini™ C3-503 CORIOmaster micro™ CORIOgrapher™ V2.5 and above Quick Start Guide V2.20 Firmware version M404 and above QSG-C3-5x0-V2.20 Jun 2017...
  • Page 3: Table Of Contents

    In this guide Welcome Hardware recommendations About your CORIOmaster™ About your CORIOmaster mini™ About your CORIOmaster micro™ About the buttons of your CORIOmaster micro™ About audio and your CORIOmaster micro™ About CORIOgrapher™ Quick start Regulatory compliance Contact us Video wall worksheet Get more help There are more Quick Start Guides available on the USB drive that came with your CORIOmaster™.
  • Page 4: Welcome

    Control your video wall with CORIOgrapher™, IP, or serial connection Horizontal alignment on analog PC inputs AMX & Crestron modules available CORIOmaster™: 4RU frame size CORIOmaster mini™: 1RU frame size CORIOmaster micro™: 1RU half rack size, up to two video walls tvONE...
  • Page 5: Hardware Recommendations

    Hardware recommendations At tvONE™, we design our products to the highest quality standards. To get the best results from our products, we recommend that you use the best quality connectors, cables, and adapters. Consider the points below when you choose accessories and position equipment.
  • Page 6: About Your Coriomaster

    CPU module controller with RS-232 Optional: connect directly to a PC with Ethernet or RS-232 Optional second PSU, Optional: connect to electrical sold separately outlet Sealed slots Not available for use Power supply unit Connect to electrical outlet (PSU) tvONE...
  • Page 7: About Your Coriomaster Mini

    About your CORIOmaster mini™ This guide uses the name CORIOmaster™ to mean CORIOmaster™, CORIOmaster mini™, and CORIOmaster micro™ systems, unless specifically stated. CORIOmaster mini™ rear panel Power supply Connect to electrical outlet unit (PSU) Connect to your network with Ethernet Optional: connect to serial controller with CPU module RS-232...
  • Page 8: About Your Coriomaster Micro

    Connect to an electrical outlet with PSU input Input module Connect to sources (black) Output module Connect to displays (white) Connect to your network with Ethernet Optional: connect to serial controller with CPU module RS-232 Optional: connect directly to a PC with Ethernet or RS-232 tvONE...
  • Page 9: About The Buttons Of Your Coriomaster Micro

    CORIOmaster micro™ mounting accessories You can mount your CORIOmaster micro™ to a surface, rack, or ONErack system with our mounting accessories, sold separately. Ask your distributor about: RM-503-1RK-MOD ONErack mounting module for CORIOmaster micro™ RM-503-1RU-DUAL rack mounting kit for one or two CORIOmaster micro™...
  • Page 10 CORIOmaster micro™ are locked. Selecting the active window You hear the active window, and you can change the source for the active window. To select the active window, press and hold the button corresponding to that window until it starts flashing. tvONE...
  • Page 11: About Audio And Your Coriomaster Micro

    Selecting a window to hear When a window is active, you hear the audio from that window. To select a window to hear, press and hold the button corresponding to that window until it starts flashing. Selecting a preset or source To select a preset or source, press and release the button corresponding to that preset or source.
  • Page 12 You can mute the audio output in CORIOgrapher™. The Streaming media and 4K playback input module only supports the following embedded audio formats: Read more about audio in CORIOgrapher™. Just select and search, or ask a question. tvONE...
  • Page 13: About Coriographer

    About CORIOgrapher™ CORIOgrapher™ is the software that controls your CORIOmaster™. You can create up to four video walls with multiple screens and windows, and add transitions and effects for a state-of-the-art dynamic video wall experience. CORIOgrapher™: Works with PCs running Windows® 7 and 10 Does not work with touch-screen-only devices, including tablets or phones Installs Windows®...
  • Page 14: Quick Start

    At the back of this guide is a plan that you can fill out. Video tearing Using a mixture of display sizes and/or resolutions can cause video tearing. For best results, make sure all your displays use the same frame rate. 2. Install your hardware. a. Position your displays. tvONE...
  • Page 15 b. Connect your displays and sources to your output and input modules. Connect the LAN port of the CPU module to your network. OPTIONAL: If you have a CORIOmaster micro™, connect a digital audio device to the S/PDIF audio output. c.
  • Page 16 4. Open CORIOgrapher™ and select your CORIOmaster™. Enter your username and password to log in, and select Read to load your configuration. The default username is admin, and the default password is adminpw. tvONE...
  • Page 17 If you aren't connected to a CORIOmaster™, you can create an offline configuration for your device. The media player of the Streaming media and 4K playback module is not available when you work in an offline configuration. 5. Optional, but recommended: name your input and output ports. Select >...
  • Page 18 7. Add a window and scale it to cover the whole video wall. Select Wall Editor > (WINDOWS) Add, and drag a window onto the wall editor. Drag the edges until it covers all of your displays. Select Take to send the video wall to your CORIOmaster™. tvONE...
  • Page 19 8. Check that your video wall looks correct. Make sure that the source for the window is playing, and check that the picture is assembled correctly. Not the source you were Source correct, connected, expecting, blue screen, display and playing. keeps dropping signal, or no Image appears in the wrong image.
  • Page 20 From the wall editor, select Audio select each window in turn from Audio Follows. You should hear the audio from the source playing in that window. Read troubleshooting advice in CORIOgrapher™ Help. In CORIOgrapher™, select and search, or ask a question. tvONE...
  • Page 21: Regulatory Compliance

    Copyright © 2017 tvONE. All rights reserved.
  • Page 22: Video Wall Worksheet

    Video wall worksheet What is my video wall layout? In the space above, draw a picture showing what kind of wall you have in mind. Show both the displays you have in mind as well as the video windows that you would like to show.
  • Page 23 How many displays or outputs are needed? How many monitors are needed? How many projectors are needed? How many LED walls are needed? Is edge blending required? What is the blending overlap size? What are the sizes of the displays? What are the bezel sizes for the monitors?
  • Page 24 What are the native resolutions of the displays? How many source signals or inputs are required? What are the source signal types? What are the source resolutions? What are the frame rates of the inputs? Will the signal feeds be available at all times that the video wall is operating?
  • Page 25 Is there any switching or processing before the signal enters the video wall processor? How many windows will be required for the video wall? Include all windows even windows that are not active at all times. What level of quality is required for each window? Not all windows can have the highest quality in most cases.
  • Page 26 In the spaces below, draw your preset destinations with window and transition attributes noted.
