Calibration for the Correct Dimension

If prints are too big or too small or skewed, user could re-calibrate the printer to
print in correct dimension. The method is to print a calibration model, measure
its dimension and feedback to the software.
L o a d a n d p r i n t t h e
calibration model:
C : \ P r o g r a m F i l e s \ U P \
Example\Calibrate96.UP3
1
Open: 3D Print - Calibrate
This will open the calibration
panel.
2
H i t " R e s e t " b u t t o n t o
revert the value back to
d e f a u l t , m a k e s u r e t h e
u p p e r p a n e l d i s p a l y :
XY:0.00 Deg/XZ:0.00 Deg
3
M e a s u r e t h e p r i n t e d
m o d e l a c c r o d i n g t h e
calibration panel.
I n p u t t h e m e a s u r e d
values into the software
and finish the calibration.
4
