must point to the spokes.
Depending on the room available, the transmitter
can be fitted at the front on the forks, inner side
of the fork or backside of the forks.
step 2 Place spoke magnet around an outer
spoke. The silver middle of the magnet points
towards the transmitter. Align the magnet to the
sensor mark on the transmitter with a gap
of about 1 – 5 mm.
Step 3 Align transmitter and magnet for good and
fasten in place: Pull cable ties tight and push
magnet in firmly.
4.2 Switching on the computer for the first time
Waking up from despatch mode
The computer is delivered with a battery installed.
To reduce the battery consumption, the computer
is put into despatch mode. The display is empty
(no display).

4.3 Installing the battery in the computer

Your VDO computer is supplied with a 3V battery
(type 2032).
The battery is already installed when supplied.
To change the battery, proceed as follows:
38 X3DW
Step 4 Decide whether fitting to handlebar or
stem and turn the base of the handlebar holder
by 90° accordingly. To do so, undo the screws in
the holder, take out the foot and turn it 90°, insert
>>> P04 and tighten the screws again.
ATTENTION: Do not over tighten screws.
step 5 Guide the cable ties through the slot in the
handlebar holder, place around the handlebars
or the stem and pull (do not pull tight just yet).
Step 6 If fitting to handlebar: Align computer
angle to achieve optimum readability. Now pull
cable ties tight. Snip off protruding ends with
clippers.
To wake it up out of despatch mode, press the
The computer is now ready for use and tells you
so by showing the language setting.
See also Chapter 4.4
step 1 Place the battery in the computer casing
with the +terminal facing up.
Step 2 Make sure that the battery does not
get wedged.
>>> P02, Display see Chapter 4.4
button simultaneously for a few seconds.
>>> P05
