A: Technical Specifications
46
Table A-2 lists other key specifications for the server.
Table A-2
Miscellaneous System Specifications
Attribute Specification
Processors
– Up to four Intel Xeon E5-4600 v3 Series processors
– LGA2011 sockets (Socket R3)
Chipset Intel PCH C612 chipset
BIOS 16 MB AMI
Memory 3 TB of LRDIMM (or 1.5 TB RDIMM) DDR4 2133/1866/1600 memory
SATA Controller Intel chipset-based controller provides support for 10 SATA 3.0 ports (RAID
0, 1, 5, and 10 supported)
Drive Bays – 24 hot-swap drive bays to house standard 2.5" drives
– One 5.25" drive day
PCI Expansion – Two PCIe
Slots – Two PCIe 3.0 x8 cards (full-height, full-length)
– Two PCIe 3.0 x8 cards (full-height, half-length)
– One PCIe 3.0 x8 card (low-profile, half-length)
– Four PCIe 3.0 x8 cards (low-profile, internal)
Onboard Graphics ASPEED
Chassis 2U standard-depth rackmount
Dimensions: (WxHxD) 19 x 3.2 x 35.9 in. (48.3 x 8.2 x 91.2 cm)
(Includes handles and power supply extension.)
Serverboard Dimensions: (LxW) 20 x 16.8 in. (50.8 x 42.7 cm)
Weight Gross: 52 lbs (23.6 kg)
System Cooling Four 8-cm high-performance fans
System Input – AC Input Voltage: 100 – 240V AC auto-range
Requirements – Rated Input Current: 13 – 4A max
– Rated Input Frequency: 50 – 60 Hz
®
SPI Flash EEPROM
®
3.0 x16 cards (full-height, full-length)
®
AST2400 BMC chip
007-6419-002
