Menu Maps

This section will help you get to your destination while letting you know what test leads you may need
when you arrive. The test leads are represented by symbols for their connectors.

Main Menu

The Main Menu is the starting point for all tools and utilities, which are depicted as icons. Some icons
lead directly to the function they represent, while others are menu icons that lead to two or more
functions. Menu icons are marked here with an asterisk (
Tests a battery using
the battery information
you select in a series of
screens.
(voltmeter reading)
*
Digital multimeter with
8 test meters, a tempera-
ture sensor, and options
for clamps and probes.
(voltmeter reading)
*
Nine utilities, many of
which customize your
user interface.
(voltmeter reading)
*
MAIN MENU (Screen 1)
Optional
Tests a battery, and the
starting and charging
systems.
MAIN MENU (Screen 2)
*
Includes a test counter,
data transfer utility, the
EXP software version
and serial number.
MAIN MENU (Screen 3)
1
• •
Chapter 2: Description
) and are mapped on the following pages.
Tests both sides of a
circuit simultaneously
for voltage. Three preset
tests and 1 user-defined.
Enables you to view your
stored test results and
print them to an optional
IR printer.
Required test leads
Battery
test
Clamps
only
an icon
*
an icon
Amp Cable
clamp drop
an icon
