Chapter 2: Description

Menu Maps

This section will help you get to your destination while letting you know what test leads you may need when
you arrive. The test leads are represented by symbols for their connectors.

Main Menu

The MAIN MENU is the starting point for all tools and utilities, which are depicted as icons. Some icons lead
directly to the function they represent, while others are menu icons that lead to two or more functions.
Menu icons are marked here with an asterisk (
Tests a battery, or bat-
teries, using the battery
information you select in a
series of screens.
Utilities, many of which
customize your user inter-
face in the tester.
) and are mapped on the following pages.
*
MAIN MENU (Screen 1)
Enables you to view your
stored test results and
print them to the internal
printer.
MAIN MENU (Screen 2)
11
• •
Displays the software ver-
sion, total tests from first
use, and the serial number.
