Chapter 3: Test Preparation
If you connect the clamps in the wrong polarity (positive to negative or negative to positive), the EXP
displays CLAMPS REVERSED! Reconnect the clamps.
To make sure both sides of the clamps are gripping the terminals, rock the each clamp back and forth.
A poor connection will prevent testing, and the EXP will display the message CHECK CONNECTION.
If the message reappears after you have correctly reconnected the clamps, clean the terminals and
reconnect.

Connecting an Accessory Cable

If you are using an accessory cable, plug it as you would a phone jack into the accessories port on
top of the EXP. It locks automatically into the port. To remove it after testing, press the lever and pull
the connector out.

Setting User Preferences

Before starting your test you may want to customize the use of your analyzer by setting preferences
in the Utility Menu. The menu has settings for the display's date and time, the contrast and backlight
time, a utility to customize printouts for the optional IR printer, among others. The utilities are described
in Chapter 10.
To conserve the analyzer's internal batteries, the EXP will turn off after 0 seconds of
inactivity.
18
• •
