Omcan MS-IT-0300-G Instruction Manual page 16

Parts Breakdown
Model MS-IT-0330-G
Item No. Description
17272 Sharpening Assembly for C330
19496 Carriage Rod C-H for C330
36549 Shock Absorber Rod 12x185 for C330
78270 Body for C330
17305 Bushing DU 18x20x15 for C330
19630 Bushing Fastener HBC for C330
36568 DU Bushing 6x8x6 for C330
16909 Sharpener Cover H-L-C for C330
19527 Carriage Assembly C for C330
36601 Rivet 1.9x5 for C330
36606 Bolt H-L-C for C330
16913 Capacitor 14 MF 400V for C330
36611 Connector L=19 for C330
36612 Connector L=23 for C330
19637 Nut M3 for C330
19638 Nut M4 for C330
36634 Nut U5587 M3.5 for C330
19639 Nut M8 for C330
36637 Nut U5589 M8 Stainless Steel for C330
Domed Nut U5721 M6 Stainless Steel
36640
for C330
36645 Normal Nut U5588 M4 for C330
19644 Nut M6 for C330
36647 Nut U5588 M8 for C330
Carriage Shock Absorber Spacer for
36661
C330
36681 Cord Holder H-L-C for C330
17349 Handle Flange for C330
36689 Stainless Steel Locknut M8 for C330
13642
Position Item No. Description
A1003 17356 Fastener Handle H-L-C for C330
B1095 36707 Switch Handle for C330
B1252 36708 Index Knob Assembly for C330
B1807 16938 Switch and Knob HL C GF 310 for C330
B6057 13598 Knife 330mm for C330
B6104B 19775 Lamp 6.3V.15A for C330
B6224 36734 Magnet 12x6 for C330
C1603 19250 Spring 24.8x1.8x15 for C330
C1901 20459 Terminal Strip for C330
C4640 20263 Motor 120V/60Hz for C330
C5002A 19805 Deflector HLC for C330
C5812 17412 Knife Guard for C330
C6008 17415 Strain Relief for C330
C6013 79238 Cable Sheath Cavoflex cm 60 for C330
D0101 17422 Pin Deflector H-L-C for C330
D0102 17423 Pivot Hinged Suport O10x22 for C330
Assembly Honing Stone Pin H-L-C for
D0104 78584
C330
Assembly Grinding Stone Pin H-L-C
D0135 17427
for C330
D0135X 36824 EL. Box Flat Bar for C330
D0153X 19831 Gauge Plate Flat Bar VS for C330
D0161 16961 Foot H/C/L VS/GL/GF for C330
D0163 36843 Carriage Plate Assembly for C330
D0165 17443 End Grip for P4425A and S7702 for C330
D5762 16964 Stud Guard Knife C for C330
F2809A 36761 Shock Absorber for C330
F6090 19657 Washer 4 for C330
G5027 17454 Washer for C330
Position Item No.
I1926 36880
I1980 17455
I1990A 16967
I3611 17457
L0608 36891
L1001 20457
M0804 17476
M7071 19871
M8005 19873
M8246 36952
P1150 16978
P1550 19887
P2008 16981
P2057 78268
P3269 37016
P3289 37017
P3380 37032
P3381 19696
P4618 19699
P4621 19702
P5008 37047
P5558 37061
P7018 37078
P7425 17497
P103401 37090
R6003 17503
R6204 37080
16
Description Position
Washer U6592 3 for C330 R6504
Washer U6592 4 for C330 R6505
Washer U65926 for C330 R6512
Washer U6592 6 Stainless Steel for
R6512X
C330
Washer 10.5x26x0.5 Stainless Steel
R6871
for C330
Circuit Board C for C330 S3201
Foot Support Pin D.10 M8 L.37 for C330 S7595
Bracket Sharpener HLC for C330 S8809
EL Box Bracket for C330 S8901
Magnet Support for C330 S8991
Blade Cover Fastener Assembly C
T5006
for C330
Blade Cover Fastener C for C330 T5036
Knife Shaft Assembly for C330 T8026
Gauge Plate for C330 V3077
Screw STTC U6113 M4x25 for C330 V6008
Screw STTC U6113 M4x30 for C330 V6009
Screw TC 6107 M3x20 for C330 V6201
Screw M3.5x12 for C330 V6204
Screw M4x25 for C330 V6231
Screw M6x25 for C330 V6246
Screw TC AUT.D7971 2.9x13 for C330 V6276
Screw TE U5739 M8x35 INOX for C330 V6411X
Stainless Steel Screw TSP U6109
V7013X
M5x12 for C330
Screw TSP U6109 M5x15 Stainless
V7014X
Steel for C330
Screw TSP AUT.U6952 4.2x16 for C330 V7086
Screw M5x13 for C330 V7908
Stainless Steel Screw M4x40 U6109
V702415
for C330
