MACHINE COMPONENTS
Electrical component box
52. Drive system electronic board
53. Drive system malfunction led. If the led
is on, the drive system is operating, if the led
ashes, the drive system is malfunctioning
54. Pillar
55. Main fuse
52
53
ICE iS1100
Continues
(
59a
54 55 56
)
56. Lamellar fuse box
57. Electronic battery charger
58. Charged battery warning light
59. Electrical component box
59a. Lamellar fuse box cover
57
58 59
