  • Page 1 CST38 User Manual VHF MICROEAR "DESKTOP" TRANSMITTER SN: ________________ Rev. 02 Date: 16 May 2017...
  • Page 2 Rev. 02 CST38 User Manual...

  • Page 3: Brief Description

    RIEF DESCRIPTION CTK38 is composed by a VHF transmitter (CST38) and a power supply (PSP910). The CST38 transmitter has been especially designed to allow best usage of MicroEar’s family “in-ear receivers” and many modulation parameters such as deviation, level/frequency curve, compression factor has been optimized. Therefore CST38 assures maximum performances of MicroEar both as sound quality and as audio level (in any case limited because of the very small size of receiver).

  • Page 4: Safety Instruction

    Rev. 02 CST38 User Manual AFETY INSTRUCTION  Read this safety instruction and the manual first  Follow all instructions and information.  Do not lose this manual.  Do not use this apparatus under the rain or near the water.

  • Page 5: Front Panel

    Rev. 02 CST38 User Manual RONT ANEL SELECTOR: modulation audio input level range (Micro / Line). LED INDICATION: peak-indicator / limiter-on status (yellow Led). ADJUSTMENT: audio input sensitivity. With the optimum sensitivity adjustment, the yellow Led [2] must flash under modulation peaks.

  • Page 6: Rear Panel

    Rev. 02 CST38 User Manual ANEL 7) CONNECTOR: antenna (N-F type connector). 8) CONNECTOR: modulation audio input (XLR3-F type connector). The audio input line is transformer balanced and floating.  pin 1 = ground;  pin 2 = AF-a input;  pin 3 = AF-b input.
  • Page 7 Rev. 02 CST38 User Manual PTIONAL VOX 38 - Voice Activated Circuit board VOX 38 board, mounted on the CST 38 main board This device is useful to switch on automatically the carrier of the transmitter only when the modulating signal is present on the TX’s input. The circuit is mounted on a printed-circuit board, that has to be factory-mounted in the transmitter.

  • Page 8: Technical Specifications

    Rev. 02 CST38 User Manual TECHNICAL SPECIFICATIONS  Switchable channels 16, preset in the 140 ÷ 250 MHz range (other upon request).  Switching-window 10 MHz (other upon request).  Frequencies microprocessor controlled PLL synthesizer circuit, with 25 kHz minimum step [1].

  • Page 9: Manufacturer Declarations

    Rev. 02 CST38 User Manual MANUFACTURER DECLARATIONS In compliance with the following requirements  RoHS Directive (2002/95/EC)  WEEE Directive (2002/96/EC) Please dispose of the diversity transmitter at the end of its operational lifetime by taking it to your local collection point or recycling center for...
  • Page 10 USA, Canada IC: 11967A-CST38 Limited to 210-216MHz CST38 is not an SRD device, thus it requires specific authorization by your local frequency authority! Before putting the device into operation, please observe the respective country-specific regulations! Statements regarding FCC and Industry Canada This device complies with Industry Canada RSS-210.
  • Page 11 Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications made to this equipment not expressly approved by Wisycom srl may void the FCC authorization to operate this equipment.
  • Page 12 Rev. 02 CST38 User Manual Wireless System Communications Via Spin 156  I-36060 Romano d’Ezzelino  Italy Tel. +39 -0424 -382605  Fax +39 - 0424 - 382733  e-mail: sales@wisycom.com www.wisycom.com...
