Javad JLink LTE User Manual page 15

Beacon Receiver (optional)
Frequency Range
User Data Rates
Sensitivity
GNSS Receiver
Tracking Channels
Signals Tracked
Cold / Warm Start
Sensitivity for Reacquisition
Environmental
Enclosure
Color
Operating Temperature
Storage Temperature
Humidity
Weight
Power Supply Voltage
Battery (optional)
* The operating temperature of Li-Ion batteries is -20 ° C to+45° C
** The storage temperature range of Li-Ion batteries is -20 ° C to +60° C
Pinout of JLink LTE power and communication port
Pin # Signal Name I/O
1 TX+/RTS_OUT O
2 RX+/CTS_IN I
3 DTR_OUT O
4 USB0_DP I/O
5 USB0_DM I/O
6 ELED+ O
7 ETD+ O
8 ERD+ I
9 PWR_IN PWR
10 TX-/TX_OUT O
11 RX-/RX_IN I
12 DSR_IN I
13 DCD_OUT O
www.javad.com
283.5- 325 kHz
50, 100, 200 bps (manual or Auto selection)
1.5 mV/m for 6 dB SNR (200 bps)
GPS/GLONASS L1
C/A Code
42 / 30 seconds
- 161dBm
aluminum, IP67
Two-tone Gray / Green
-40° C to +70° C *
-40° C to +85° C **
100% condensing
468 g / 970 g
+5.5...36V without battery charging, 4Amax
+12...34V when the battery is charged, 3.6Amax
One embedded, 7.2V, 5850 mAh
Description
Transmit Data positive line (RS-422) /
Request to Send (RS-232)
Receive Data positive line (RS-422) /
Clear to Send (RS-232)
Data Terminal Ready (RS-232)
Data Positive line (USB)
Data Negative line (USB)
LED line (LAN)
Transmit Data positive line (LAN)
Receive Data positive line (LAN)
+5.5 to +36 VDC Power Input
Transmit Data negative line (RS-422) /
Transmit Data (RS-232)
Receive Data negative line (RS-422) /
Receive Data (RS-232)
Data Set Ready (RS-232)
Data Carrier Detect (RS-232)
Communication Ports
Wi-Fi 2.4 and 5 GHz (IEEE 802.11 a, b, g, n, d,e,i)
Full-duplex 10BASE-T/100BASE-TX Ethernet port
Bluetooth 4.1 Compliance and CSA2 Support
Dual-Mode Bluetooth and Bluetooth LE
High Speed USB 2.0 configurable as Device or Host port
MicroSD card slot (fully sealed)
Serial port configurable as RS232/RS422/RS485
Pin # Signal Name I/O
14 USB0_VBUS PWR
15 USB0_ID I
16 ETD- O
17 ERD- I
18 PWR_IN PWR
19 GND PWR
20 GND PWR
21 GND PWR
22 RESERVE -
23 RESERVE -
24 RESERVE -
25 RESERVE -
26 PWR_IN PWR
Description
Power line (USB)
USB0 ID line
Transmit Data negative line (LAN)
Receive Data negative line (LAN)
+5.5 to +36 VDC Power Input
Power Ground
Power Ground
Power Ground
Not used. Reserve
Not used. Reserve
Not used. Reserve
Not used. Reserve
+5.5 to +36 VDC Power Input
