Specifications

4G cellular module
4G LTE Mini Card (option 1)
Technology:
LTE
UMTS (WCDMA), HSDPA,
HSUPA, HSPA+,DC-HSPA+
GSM, GPRS, EDGE
4G LTE Mini Card (option 2)
Technology:
LTE
CDMA (EVDO Rel. 0 and Rel.A)
UMTS (WCDMA), HSDPA,
HSUPA, HSPA+,DC-HSPA+
GSM, GPRS, EDGE
UHF/VHF Radio (optional)
Frequency Range 406-470 MHz/138-174 MHz
Channel Bandwidth 25/20/12.5/6.25 kHz
Modulation DBPSK/DQPSK/D8PSK/D16QAM/4FSK/GMSK
Transmitter Output Power 1W (+30 dBm)
Communication Mode Half duplex, simplex, repeater
14
LTE, DC-HSPA+, HSPA+, EDGE, GPRS, GSM and CDMA networks
Bands: 1 (2100 MHz), 3 (1800MHz), 7 (2600 MHz), 8 (900 MHz), 20 (800 MHz)
Data Rates: Category 3
Downlink 100 Mbps (20 MHz bandwidth), 50 Mbps (10 MHz bandwidth)
Uplink 50 Mbps (20 MHz bandwidth), 25 Mbps (10 MHz bandwidth)
Bands: 1 (2100 MHz), 2 (1900 MHz), 5 (850 MHz), 6 (800 MHz), 8 (900 MHz)
Data Rates: HSPA+ rates
Downlink up to 42 Mbps (category 24)
Uplink up to 5.76 Mbps (category 6)
GSM 850 (850 MHz), EGSM 900 (900 MHz), DCS 1800 (1800 MHz), PCS 1900 (1900 MHz)
Data Rates: EDGE throughput up to 236 kbps
LTE, DC-HSPA+, HSPA+, EDGE, GPRS, GSM and CDMA networks
Bands: 2 (1900 MHz), 4 (AWS) (1700/2100MHz), 5 (850 MHz), 13 (700 MHz), 17 (700 MHz), 25 (1900 MHz G Block)
Data Rates: Category 3
Downlink 100 Mbps (20 MHz bandwidth), 50 Mbps (10 MHz bandwidth)
Uplink 50 Mbps (20 MHz bandwidth), 25 Mbps (10 MHz bandwidth)
Bands: BC0 (Cellular 800 MHz), BC1 (PCS 1900 MHz), BC10 (Secondary 800 MHz)
Data Rates: CDMA IS-856 (1xEV-DO Release A)
Up to 3.1 Mbps forward channel
Up to 1.8 Mbps reverse channel
CDMA IS-2000
Up to 153 kbps, simultaneous forward and reverse channels
Bands: 1 (2100 MHz), 2 (1900 MHz), 4 (AWS 1700/2100 MHz), 5 (850 MHz),8 (900 MHz)
Data Rates: HSPA+ rates
Downlink up to 42 Mbps (category 24)
Uplink up to 5.76 Mbps (category 6)
GSM 850 (850 MHz), EGSM 900 (900 MHz), DCS 1800 (1800 MHz), PCS 1900 (1900 MHz)
Data Rates: EDGE throughput up to 236 kbps
ISM Radio (optional)
Frequency Range
Modulation
Data Rate of Radio Interface
(USA/Australia)
Data Rate Radio Interface (EU)
Transmitter Output Power
Communication Mode
902-928 MHz (USA)/
915-928 MHz (Australia)/
868-870 MHz (EU) with 25/12.5 kHz CS
GMSK
64000 bps
9600 bps
1W (+30 dBm)
Half duplex, simplex, repeater
