IQ PANEL USER GUIDE
S E C U R I T Y &
SMARTHOME
We hope you enjoy your new IQ Panel security and smarthome platform. It will serve as the "brain"
of your home for many years to come. With it you can control your lights, locks, thermostat, security
and much more.
You won't need a manual to operate your IQ Panel, but you can use this guide to learn more about
the features of this amazing new device. We hope it will add to your home' s decor and make your
home smarter and more energy efficient!
-The Qolsys team
Document: IQP2-07-16
Revised on: 9/19/16
Software Version: 2.0
Qolsys Part #: TBD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IQ Panel and is the answer not in the manual?

Questions and answers

Related Manuals for QOLSYS IQ Panel

Summary of Contents for QOLSYS IQ Panel

  • Page 1 You won’t need a manual to operate your IQ Panel, but you can use this guide to learn more about the features of this amazing new device. We hope it will add to your home’ s decor and make your...

  • Page 2: Getting Started

    GETTING STARTED Let’s start by connecting your power. (note: if your panel has been professionally installed, skip this page) Plug in the power connector Route the wire behind the Insert the wire into the strain- retainer clip relief Now let’s put on your cover and attach the table stand. Place the top of the cover onto Push the cover down until it Insert the table stand into the...
  • Page 3 USING YOUR SYSTEM: BASICS Navigation Move from page to page and access information on each page using finger touches, Swipe down to swipes, and scrolling. access settings Scroll up/down to reveal additional content on a page Swipe left/right to change pages Touch an icon to view its contents Dismiss...

  • Page 4: Message Center

    USING YOUR SYSTEM: MESSAGE CENTER Message Center Access your message center by touching the icon in the upper right corner. Once it’ s open you’ll see three sections: Contact, Video Tutorials, and Messages/Alerts/Alarms (Note: This icon may appear different than shown, depending on your provider’ s settings) Contact Easy access to your provider’...

  • Page 5: Emergency Panic

    USING YOUR SYSTEM: EMERGENCY PANIC Emergency Panic If you have a police, fire, or medical emergency and your system is not armed or a sensor has not been triggered, you can send a manual emergency panic by touching the icon in the bottom right corner and selecting the type of emergency you are experiencing.

  • Page 6: Additional Arming Options

    USING YOUR SYSTEM: ARMING Sensor List Open or active sensors appear in a scrollable list on the right. Touch the icons in the upper right corner to switch your view to either “Active” or “All” sensors. Sensor status: Open Closed Active Idle Touch to access...

  • Page 7: Disarming Your System

    Pair Disarming Automatically You can connect your smartphone using Bluetooth and it will automatically disarm your IQ Panel from an “Armed Away” state when *You can connect up to five (5) smartphones for touchless disarming. Before you begin you must it comes within range.

  • Page 8: Alarm Events

    ALARM EVENTS Alarms If the alarm is triggered the IQ Panel will sound the siren and display a red alarm screen. Police When the system is armed and the alarm is tripped or you touch the “Police” emergency button the alarm sounds with the “Intrusion”...

  • Page 9: Full Screen

    Touch it again to return to the camera page. Camera Page Your IQ Panel’ s built in camera captures photos in a variety of situations: Note: While viewing photos full screen Disarm Photos you can swipe left/right to view...
  • Page 10 USING YOUR SYSTEM: SETTINGS Settings Tray Access common settings by swiping down from the top of the screen. HOW TO ACCESS: Security Status Battery & Radios See your panel’ s Touch an icon to get security status in the more information upper right.

  • Page 11: Photo Frame

    SETTINGS: PHOTO FRAME Photo Frame When your panel is not in use, it turns into a customizable photo frame. Settings Inside settings you can choose whether you want photos or a weather clock, if you want the panel to turn itself off automatically in the evenings, and more.

  • Page 12: User Types

    SETTINGS: ADDING A USER User Types You can add up to 242 users to your system, each with a custom name and access you allow. Master: Access panel functions, camera, and system settings. User: Access panel functions, camera, but NOT system settings. Guest: Used to give arm and disarm access to those users who will use the panel on a Notifications...

  • Page 13: Sensor Test

    SETTINGS: TESTING YOUR SYSTEM Testing Regularly You should test your system regularly to ensure it is operating at peak efficiency. The IQ Panel has a number of tests built in that are easy to perform: Wi-Fi Test How to Access System Tests Run this test every 30 days or if the IQ Panel’...

  • Page 14: Light Control

    Light Control You can add up to 80 Z-Wave lights, lamp modules, or lightbulbs to your IQ Panel. This will allow you to control your lights locally on the panel and also from your mobile app. Once your first light is added to your system, the lights page will appear.

  • Page 15: Lock Control

    Lock Control You can add up to 6 Z-Wave locks to your IQ Panel. This will allow you to control your locks locally on the panel and also from your mobile app. Once your first lock is added to your system, the lock page will appear.

  • Page 16: Thermostat Control

    Thermostat Control You can add up to 6 thermostats to your IQ Panel. This allows you to control the temperature in your home locally on the panel and also from your mobile app. Once your first thermostat is added to your system, the thermostat page will appear.
  • Page 17 Garage Control You can add up to 10 Z-Wave overhead garage door controllers to your IQ Panel. This allows you to control the door from your panel and also from your mobile app. Once your first thermostat is added to your system, the thermostat page will appear.

  • Page 18: Image Sensors

    USING YOUR SYSTEM: IMAGE SENSOR Image Sensors You can add up to 5 Image Sensors to your IQ Panel. This allows you to see the photos taken by your image sensors locally on the panel and also from your mobile app. Once your first Image Sensor is added to your system, the Image Sensor page will appear.

  • Page 19: Troubleshooting

    TROUBLESHOOTING Rebooting your panel If you experience any problems with your panel, you can reboot the operating system How to Reboot Step 1: Swipe down to access settings tray Step 2: Touch “SETTINGS” Step 3: Touch “ADVANCED SETTINGS” Step 4: Enter your master code Step 5: Touch “Panel Reboot”...

  • Page 20: Software Updates

    SOFTWARE UPDATES Software Updates Be sure you panel is always using the latest software How to check for updates Step 1: Swipe down to access settings tray Step 2: Touch “SETTINGS” Step 3: Touch “ADVANCED SETTINGS” Step 4: Enter your master code Step 5: Touch “Software Upgrade”...

  • Page 21: Fcc Regulatory Information

    FCC/IC STATEMENT Changes or modifications not expressly approved by Qolsys can void the user’ s authority to operate the Product. This Product has been tested and found to comply with FCC Rules.

  • Page 22: Household Fire Safety Audit

    LEGAL This Product generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this Product does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna.
  • Page 23 LEGAL 5.Each person should know the predetermined assembly point where everyone can be accounted for (e.g., across the street or at a neighbor's house). Once everyone is out of the building, call the fire department. 6.A good plan emphasizes quick escape. Do not investigate or attempt to fight the fire, and do not gather belongings as this can waste valuable time.
