8-23. REMOVAL OF TURBOCHARGER.

a. Remove the upper cowling. (Refer to Paragraph 8-5.)
b. Remove the turbocharger compressor and turbine assembly by the following procedure:
1. Disconnect the oil supply and return lines from the center section of the turbo.
2. Disconnect the air ducts from the compressor inlet and outlet and the exhaust system from the
turbine inlet and outlet.
3. Remove safety wire securing the turbine insulation blanket and remove blanket.
4. Remove the bolts that attach the turbocharger to the mounting bracket and remove the
turbocharger assembly.
Comply with instructions of latest revision of Piper Service Bulletin No. 844.
Piper considers service bulletins of utmost importance and compliance
mandatory.

8-24. INSTALLATION OF TURBOCHARGER.

a. Position turbocharger assembly on the mounting bracket and secure with attaching hardware.
b. Align exhaust system manifold turbo inlet and the turbine inlet and secure with clamp temporarily.
The turbocharger is properly installed with the large diameter center clamp
loose to allow rotation of the turbine housing during installation for proper
alignment with the exhaust system inlet connection. Tighten clamp after
alignment.
When tightening any of the three V-band clamps, it is necessary to tap the
clamp all around its circumference to ensure proper seating. Do not rely on
tightening alone for proper clamp seating.
Revised: 2/13/89
CHEROKEE ARROW III SERVICE MANUAL
WARNING
NOTE
NOTE
POWER PLANT - CONTINENTAL
2B3
