TABLE II-I. LEADING PARTICULARS AND PRINCIPAL DIMENSIONS (cont.)
MODEL
ENGINE (cont.)
Starter - Prestolite (12-volt)
Alternator:
Chrysler (60 AMP)
Prestolite (60 AMP)
Prestolite (65 AMP)
Alternator Voltage Regulator, WICO
Alternator Overvoltage Relay, WICO
PROPELLER - Constant Speed
Manufacturer
Hub, Model
Blade, Model
Diameter (in.)
Diameter, Minimum (in.)
Blade Angle, Low Pitch*
Blade Angle, High Pitch*
Governor Control and Model
*Measured at 30 inch station.
LANDING GEAR
Type
Shock Strut Type
Fluid Required (Struts, Hydraulic
System and Brakes)
Strut Exposure (Exposure under
Static Load):
Nose
Main
Wheel Tread
Wheel Base
Nose Wheel Travel
Revised: 12/11/78
*CHEROKEE ARROW III SERVICE MANUAL
PA-28R-201
MZ4206
2642997
ALY-6422
X16300B
X16799B
McCauley or Hartzell
B2D34C213
90DHA-16
74.0
73.0
12.5° ± 0.2°
29.8° ± 0.5°
Hartzell F-2-7 (AZ)
Hydraulically
Combination Air-Oil
MIL-H-5606A
2.75 ± .25 in.
2.00 ± .25 in.
10 ft. 5.72 in.
7 ft. 10.38 in.
30° ± 2° left and right
HC-C2YK-1( ) F
F7666A-2R
74.0
72.5
14.0° ± 0.2°
29° ± 2°
Retractable
1B1
PA-28R-201T
MCL-6501
ALX-9425A
X16300B
X16799B
Hartzell
BHC C2YF-1-BF
F8459A-8R
76.0
75.0
14.4° ± 0.2°
29° ± 1.0°
Hartzell E-5 or
Woodward G210681
Hydraulically
Retractable
Combination Air-Oil
MIL-H-5606 A
2.75 ± .25 in.
2.00 ± .25 in.
10 ft. 5.72 in.
7 ft.10.38 in.
30° ± 2° left and right
HANDLING AND SERVICING
