Acura/Honda/Isuzu 1988-2006
AT-807HD, IBR-807HD, CF-807HD, AW-807HD
KIT FEATURES
• DIN radio provision
• ISO DIN radio provision
KIT COMPONENTS
• A) Radio housing (a) • B) Radio housing (b) • C) Trim plate (a) • D) Trim plate (b) • E) ISO spacers
• F) ISO brackets (a) • G) ISO brackets (b) • H) Radio brackets • I) Rear support bracket (a) • J) Rear support
bracket (b) • K) (2) #8 x 3/4" Phillips pan head screws • L) (6) #8 x 3/8" Phillips pan head screws
A
B
H
I
J
METRA - The World's best kits
Installation instructions for part INST-7898
99-7898
C
D
E
K
L
®
®
F
G
metraonline.com
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness:
• Please visit metraonline.com for more information
Antenna Adapter:
• Not Required
TOOLS REQUIRED
• Phillips screwdriver • Cutting tool
• Panel removal tool • 8mm socket wrench
CAUTION!
All accessories, switches, climate controls panels, and
especially air bag indicator lights must be connected before cycling
the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
© COPYRIGHT 2016 METRA ELECTRONICS CORPORATION
