3. Hardware Setup
Locations and Settings of Internal Connectors and
Jumpers
When you remove the top cover and hard disk bracket, the
connectors, jumpers, and switches are laid out as shown in the figure
below:
IPC-PT/L630S(PCI)C,
IPC-PT/L630S(PCI)CP
Figure 3.3. Locations and Settings of Jumpers, Connectors,
20
IPC-PT/H630X(PCI)C,
IPC-PT/H630X(PCI)CP
and Switches inside the Top Cover
(IPC-PT/L630S(PCI)C,
IPC-PT/L630S(PCI)CP,
IPC-PT/H630X(PCI)C,
IPC-PT/H630X(PCI)CP)
User's Manual
