Var droop [%]
Range 0 – 20%
This setpoint defines the slope of the VAr droop correlation. The slope is set as a droop of voltage in
percentages of the generator nominal voltage (Basic settings: GenNomV) on the range of the requested
reactive power from 0 to 100% of nominal reactive power (value of nominal reactive power is not given by
setpoint but it is calculated from setpoint Nomin power whilst the PF=0,8).
VarDroopOffset [%]
Range 0 – 20%
This setpoint defines the value of requested reactive power on the nominal voltage (Basic settings:
GenNomV). Allows to shift the droop correlation line up or down.
TauVoltActuat
Time constant of the voltage regulator connected to the binary Up/Down outputs. This is to match the
reaction of the controller's regulator with the actual reaction time of the voltage regulator.
Step: 0,1 s
Range: 1,0 - 300,0 s

Force value:

Yes
Hint:
Use this for older generators where motorised potentiometer is used for voltage adjust to the AVR.
Force value
Force value 1-16
„Source" setpoints containing the alternative values for selected „target" setpoints. The setpoint with index X
corresponds to the Force value Xth function. Procedure description see in GenConfig-x.y User guide.
Hint:
As the "source" for Force value channel can be used any compatible value in the controller (in general all
values and setpoints of types integer8,16,32). In that case the corresponding Force value X setpoint is
unused on that channel.
ExtValue1LoLim
ExtValue2LoLim
ExtValue3LoLim
ExtValue4LoLim
ExtValueX low limit. The value is not decreased under this limit, even if the request still exists (via binary
input ExtValueX down).
Step: 1 X
-32000 – ExtValueXHiLim X
Range:
Inteli NT GeCon-MARINE MINT, SW Version 3.2, ©ComAp – July 2015
IGS-NT-GeCon-MARINE-MINT-3.2.PDF
(FV)
(FV)
[ s ]
[ X ]
[ X ]
[ X ]
[ X ]
[ X ]
91
