Specifications - Fluke 1623-2 User Manual

1623-2
Users Manual

Specifications

Temperature ranges
Operating temperature range:
Storage temperature range:
Temperature coefficient:
Operating humidity:
Operating altitude:
Climatic class:
Protection type
Case:
Battery door:
Electromagnetic compatibility:
Safety:
External voltage:
Noise rejection:
Measurement time:
Maximum overload:
Batteries:
Battery life span:
Dimensions:
Weight with batteries:
Memory:
RA 3-Pole and 4-Pole ground resistance measurement
Resolution
0.001 ... 10 Ω
For 2-pole measurements, connect terminals H and S with the supplied
connector cable.
30
0 °C to +35 °C (+32 °F to +95 °F)
-20 °C to +60 °C (-4 °F to +140 °F)
±0.1 % of rdg / °C (below 18 °C and above 28 °C)
<95 % RH noncondensing
2000 m
C1 (IEC 654-1), -5 °C to +45 °C, 5 % to 95 % RH
IP56
IP40
Complies with IEC61326-1: Portable
Complies with IEC 61010-1: CAT None, Pollution Degree 2
U , max = 24 V (dc, ac < 400 Hz), measurement inhibited
ext
for higher values
>120 dB (162/3, 50, 60, 400 Hz)
6 seconds, typical
250 V
6 x 1.5 v, AA, LR6 Alkaline
>3000 measurements, typical
240 mm x 180 mm x 110 mm (9.5 in x 7.1 in x 4.4 in)
1.49 kg (3.28 lb)
Internal memory storage up to 1500 records
accessible via USB port
Measurement range
0.020 Ω to 19,99 kΩ
(pertains to misuse)
rms
Accuracy
±(2 % rdg + 3 d)
Note
Operating error
±(5 % rdg + 3 d)
