Summary of Contents for Fluke 1620A DEWK
- Page 1 1620A “DewK” Thermo-Hygrometer Getting Started January 2003 Rev. 1, 3/13 © 2003-2013 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
- Page 2 Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers only but have no authority to extend a greater or different warranty on behalf of Fluke. Warranty support is available only if product is purchased through a Fluke authorized sales outlet or Buyer has paid the applicable international price.
-
Page 3: Table Of Contents
Table of Contents Before You Start ................1 Introduction ......................1 Symbols Used .....................1 Safety Information ....................3 WARNINGS ........................3 CAUTIONS ........................4 Authorized Service Centers ................4 Specifications and Environmental Conditions ......7 Specifications .....................7 Environmental Conditions ...................8 Quick Start ..................9 Unpacking ......................9 Use Proper Care ....................9 Learn About the Features and Components ............9... - Page 4 Battery ......................17 Sensor Configuration ..................18 Power Switch ....................18 Power On Self-Test ...................18 Display Contrast ....................18 Display ......................18 Alarm Screen ....................18 Measuring ......................19 Unit of Temperature ..................19 Recording Measurements.................19 Sensors ......................19 Sensor Accuracy ....................... 19...
-
Page 5: Before You Start
1 Before You Start... - Page 6 1620A “DewK” Thermo-Hygrometer Getting Started Symbol Description Battery Complies with European Union directives Double Insulated Electric Shock Fuse PE Ground Hot Surface (Burn Hazard) Read the User’s Guide (Important Information) Canadian Standards Association OVERVOLTAGE (Installation) CATEGORY II, Pollution Degree 2 per IEC1010-1 refers to the level of Impulse Withstand Voltage protection provided.
-
Page 7: Safety Information
1 Before You Start Symbol Description The European Waste Electrical and Electronic Equipment (WEEE) Directive (2002/96/ EC) mark. Safety Information Use this instrument only as specified in this manual. Otherwise, the protection provided by the instrument may be impaired. The following definitions apply to the terms “WARNING” and “CAUTION”. “WARNING”... -
Page 8: Cautions
Keep the sensors clean and away from fluids and dust. Authorized Service Centers Please contact one of the following authorized Service Centers to coordinate service on your Hart product: Fluke Corporation, Hart Scientific Division 799 E. Utah Valley Drive American Fork, UT 84003-9775 Phone: +1.801.763.1600 Telefax: +1.801.763.1010... - Page 9 1 Before You Start Phone: +86-10-6-512-3436 Telefax: +86-10-6-512-3437 E-mail: xingye.han@fluke.com.cn Fluke South East Asia Pte Ltd. Fluke ASEAN Regional Office Service Center 60 Alexandra Terrace #03-16 The Comtech (Lobby D) 118502 SINGAPORE Phone: +65 6799-5588 Telefax: +65 6799-5588 E-mail: antng@singa.fluke.com...
-
Page 11: Specifications And Environmental Conditions
2 Specifications and Environmental Conditions Specifications and Environmental Conditions Specifications Temperature Range 0 °C to 50 °C Temperature Accuracy 16 °C to 24 °C (60.8 °F to 75.2 °F): ± 0.125 °C (± 0.225 °F) [calibrated] (“H” Model) 0 °C to 16 °C (32 °F to 60.8 °F): ± 0.5 °C (± 0.9 °F) [uncalibrated typical] 24 °C to 50 °C (75.2 °F to 122 °F): ±... -
Page 12: Environmental Conditions
Maintenance section of the User’s Guide. For full accuracy, operate the instrument within the calibrated temperature and relative humid- ity range of the sensors. 1620A DewK Operating Temperature: 0 °C to 50 °C (32 °F to 122 °F) Relative Humidity: 0% to 70 %RH 2626-H/S Operating Temperature: 0 °C to 50 °C (32 °F to 122 °F) -
Page 13: Quick Start
3 Quick Start Quick Start This section briefly explains the basics of setting up and operating your thermo-hygrometer. Unpacking Carefully unpack the thermo-hygrometer and inspect the instrument to make sure all compo- nents are present and in satisfactory condition. Verify that the following items are present: 1620A Thermo-Hygrometer AC adapter and power cord Serial cable... -
Page 14: Connect The Sensor
1620A “DewK” Thermo-Hygrometer Getting Started Guide Connect the Sensor The sensor for channel 1 connects to the socket at the top-right, and the sensor for channel 2, if used, connects to the socket on the right side. Either sensor may be used with an optional exten- sion cable up to 100 feet (30 meters) in length. -
Page 15: Parts And Controls
4 Parts and Controls Parts and Controls The functions of the various features of the thermo-hygrometer are described below. Front Panel The front panel buttons ENTER/MENU, Up/Down/Left/Right Arrows, and EXIT are used to select and alter the functions of the thermo-hygrometer (see Figure 1). Figure 1. -
Page 16: Top Panel
1620A “DewK” Thermo-Hygrometer Getting Started Guide ENTER/MENU - This button is used to select a menu item, to accept a choice, or save changes to a parameter. EXIT - This button is used to return from a menu or window or cancel changes to a parameter. Pressing the Exit button for a second or so returns from most any menu, menu function, or window back to the main screen. -
Page 17: Back Panel
4 Parts and Controls Alarm Port - The alarm port allows external alarm indicators to be connected to the instrument and activated when an alarm event occurs. The port outputs 0V when inactive and 12V DC (up to 20 mA) when active. The jack accepts a 2.5 mm two-conductor subminature plug (Switch- craft #850). -
Page 18: Quick Buttons
1620A “DewK” Thermo-Hygrometer Getting Started Guide Battery Compartment - The battery compartment holds a 9V alkaline battery used as a backup power source to maintain continuous measurement during a power outage. Power Switch - The power switch turns the power on and off to the thermo-hygrometer, includ- ing power from the battery. -
Page 19: Accessories
4 Parts and Controls Model 1620A-S includes a 1620A Thermo-Hygrometer readout, a standard accuracy sensor (Model 2626-S), a thermo-hygrometer readout wall mount bracket, power supply (Model 2361), and an RS-232 cable. Accessories The following accessories are available to compliment either the high accuracy or standard thermo-hygrometer readout. -
Page 21: General Operation
5 General Operation General Operation This section explains basic operation of the thermo-hygrometer. Detailed operation of the thermo-hygrometer is explained in Sections 7 and 8 of the User’s Guide. Section 7 explains the menu structure and the functions available in the menu structure and Section 8 explains the communications interface for operating the thermo-hygrometer remotely. -
Page 22: Sensor Configuration
1620A “DewK” Thermo-Hygrometer Getting Started Guide Replace the battery cover. Replace the DC power cord and switch the power on. Used batteries must be disposed of properly. See the WARNINGS section at the beginning of this guide. Sensor Configuration The thermo-hygrometer can be used with one or two sensors of either type attached at either of the two ports. -
Page 23: Measuring
5 General Operation Measuring The thermo-hygrometer will automatically make measurements on enabled channels at the set period when a sensor is attached. Channels are enabled using the CHANNEL SETTING func- tion in the CHANNEL menu. The measurement period is also set with this function. Unit of Temperature The thermo-hygrometer is capable of displaying temperature in Celsius (C) or Fahrenheit (F). - Page 24 1620A “DewK” Thermo-Hygrometer Getting Started Guide First, consider that the sensor actually measures its own temperature, not necessarily the tem- perature of the air around it. Ideally, the sensor’s temperature will be the same as the air, but they might be different under less than ideal conditions. One such condition is when there is a source of radiated heat that is “seen”...
- Page 25 5 General Operation...
