- Page 1 Installation and Maintenance Manual Commercial Sliding Gate Operator : GDS 450 LVL ODEL SPEED MCS V2 E WITH LSEMA CLIPSE OPERATING SYSTEM & ADE IN USTRALIA FROM USTRALIAN QUALITY IMPORTED COMPONENTS A.B.N. 62 059 806 405 Nov 2016 V1.00 N14870...
-
Page 2: Table Of Contents
CONTENTS Section No Page No Safety Precautions Wiring Requirements Installation details Plan view/Operator Dimensions Mechanical Installation Electrical Connections/Control Inputs/Outputs Control board layout Factory Parameter Settings Commissioning Programming remote controls Manual Release Maintenance details Warranty... -
Page 3: Safety Precautions
AFETY RECAUTIONS WARNING! FAILURE TO FOLLOW THESE SAFETY PRECAUTIONS AND INSTALLATION INSTRUCTIONS COULD RESULT IN INJURY OR DEATH AND OR DAMAGE TO PROPERTY AND EQUIPMENT Appropriately licensed and competent personnel only should install the automation equipment. The operators are designed specifically to open and close sliding gates or doors and should not be used for any other purpose. -
Page 4: Wiring Requirements
IRING EQUIREMENTS - The operator can be connected to a suitable 240v a.c 10A power circuit provided it is done so by a licensed person and rules in AS/NZS 3000:2007 are adhered to. - The operator can be ordered with separate power supply remote from operator making it easier to run low voltage to the operator in situations where its difficult or not practical to run 240v ac. -
Page 5: Mechanical Installation
Mechanical Installation 1. Check that the gate runs smoothly throughout its travel and does not bind anywhere. 2. IMPORTANT Ensure gate stops are fitted at the fully open and closed positions. These stops need to be engineered and installed in such a way that they will be strong enough to stop the gate should the limits fail at any time. -
Page 6: Electrical Connections
Electrical Connections Supply A,N,E 240v 3A fused input terminals are provided pre wired with a 3 pin plug top. Supply transformer rated at 240vac primary, 24vac 160VA secondary. A 20A Blade fuse is fitted on the board. (this fuse rating must not be exceeded, doing so will void warranty) Power for accessories 12v dc 250 ma regulated supply available at the control board terminals. -
Page 7: Control Board Layout
Control Board Layout ACTORY PARAMETER SETTINGS If the control board has been reset, these parameters will have to be checked and adjusted as required. PARAMETER ETTING ALUE ORMAL AUTOCLOSE ON SEQUENTIAL OBSTRUCTIONS OPEN OBSTRUCTION MARGIN CLOSE OBSTRUCTION MARGIN OPEN AND CLOSE SLOW SPEED OBSTRUCTION MARGIN M OBSTRUCTION DETECTION RESPONSE TIME FAST PEED DETECTION RESPONSE TIME... -
Page 8: Commissioning
OMMISIONING Commissioning can only commence once all wiring is complete, and all of the mechanical installation is complete and checked including checking of all fixing bolts for tightness. If there is no obstructions in the way of the gate travel, with no vehicle traffic, and no pedestrian traffic. If the site is busy, necessary traffic/pedestrian barriers and warning signs must be in be in place before operating the gate. -
Page 9: Manual Release
ANUAL ELEASE NSTRUCTIONS Place key in door lock, turn clockwise till released and pull door open Turn knurled knob anticlockwise approx. ½ a turn to release. With the clutch door open this disengages the door switch which in turn inhibits the operation of the operator. Gate can now be opened by hand. -
Page 10: Maintenance Details
AINTENANCE ETAILS WARNING! Failure to maintain equipment may result in injury or death and/or damage to property and equipment Recommended maintenance to be performed on the operator and gate are as follows:- Operator performs over 150 cycles a day each month Operator performs between 100-150 cycles a day every 2 month Operator performs between 50-99 cycles a day... -
Page 11: Warranty
Warranty RIVE YSTEMS USTRALIA WARRANTS THAT THE GOODS MANUFACTURED BY IT SHALL BE FREE FROM DEFECT IN MANUFACTURE FOR A PERIOD OF MONTHS FROM THE DATE OF INVOICE HOULD ANY FAULT OCCUR WITHIN THAT PERIOD AS A RESULT OF FAULTY WORKMANSHIP OR MATERIALS RIVE YSTEMS USTRALIA AT ITS DISCRETION...
