- Page 1 Installation and Maintenance Manual Light Industrial Swing Gate Operators Model: GDS 3 A.B.N. 62 059 806 405 March 2017 V1.01...
-
Page 2: Table Of Contents
CONTENTS Page Standard Installation Side-Mount Installation Restricted Side Room Outswing Installation Circuit Board Settings Options Transmitter – Poor Range Specifications Emergency Release Maintenance Warranty... -
Page 3: Standard Installation
3. Position each unit on the gate pillars or posts approximately 50mm from the edge of the pillar. The vertical position is found by locating the gate bracket. This is best placed where there is adequate fixing on the gate and movement of the arms is unrestricted (Figure 2). - Page 4 Connect the slave to the master unit with 2 core flex (maximum load 8Amp at 12volts) (Figure 3) Figure 3: Master/Slave connections The units are set in the factory for a standard installation with the master placed on the left hand side (from inside looking out).
-
Page 5: Side-Mount Installation
Primary arm. 3. Move the Primary arm to its maximum open position. Open the gate and measure the distance again (Figure 8). If the length has changed then the gate bracket must be repositioned and the process repeated until the dimension remains the same for both positions. -
Page 6: Outswing Installation
OUTSIDE Pillar Open Gate Leaf Open Gate INSIDE 3ODQ 9LHZ Figure 8: Re-measure length of Secondary arm 4. Once the dimension is consistent, a new hole can be drilled in the Secondary arm and the arm trimmed to suit. The gate bracket and Secondary arm should now be fitted. UTSWING NSTALLATION In this type of installation the gate swings outward or away from the operators to the open position (Figure... -
Page 7: Options
On Board Version 2.3 or later, there is a Travel Timer – yellow L.E.D. trimpot. This should be set approximately 5 to 10 seconds after full operation after gates reach full travel on limits in open and closed position. Travel times can be adjusted by turning trimpot anticlockwise to extend travel time and vice versa. -
Page 8: Transmitter - Poor Range
NSECTS The Light Industrial Operators have been designed to minimise infestation by insects. Additional protection is recommended by spraying of a Surface Spray to the area surrounding the unit every 3 months. UBRICATION The gears and shafts are greased on assembly. They should not require further lubrication during their... -
Page 9: Warranty
ARRANTY Gate Drive Systems Australia warrants that the goods manufactured by it shall be free from defect in manufacture for a period of 12 months from the date of invoice. Should any fault occur within that period as a result of faulty workmanship or materials, Gate Drive Systems Australia at its discretion, replace the product at no charge to the Customer except for installation &...
