1.0 Introduction

1.0 Introduction

HLHF200 is a perfect solution for transmitting HDMI audio and video through the fiber, the set of device includes

a sender of Tx and a receiver of Rx. Our products transmit the HD video over optical fiber, which making the

images clearer as well as the transmission more stable. At the same time, the product has the built-in IR remote

control function.

2.0 Panel Description

USER MANUAL

HDMI Fiber Optic Transmission

Table of Contents

Do you have a question about the HLHF200 and is the answer not in the manual?

Page 1 1.0 Introduction HLHF200 is a perfect solution for transmitting HDMI audio and video through the fiber, the set of device includes a sender of Tx and a receiver of Rx. Our products transmit the HD video over optical fiber, which making the images clearer as well as the transmission more stable.
Page 2 HDMI TX HDMI RX HDMI PORT Video Input Video Output IR PORT IR Input IR Output Fiber Port SC Optic-fiber Data Transmission Hold down the key for 8 seconds after power on, the RESET KEY model will restore default settings 2.2 Indicator led.
Page 3 Video Parameter 640X480 @ 60fps 800X600 @ 60fps 1024X600 @ 60fps 1024X768 @ 60fps 1152X864 @ 60fps 1280X600 @ 60fps 1280X720@ 60fps 1280X768@ 60fps Video Resolution 1280X800@ 60fps 1280X960@ 60fps 1280X1024@ 60fps 1440X1050@ 60fps 1440x900 @ 60fps 1600x900 @ 60fps 1660x1200 @ 60fps 1680x1050 @ 60fps 1920x1080 @ 60fps Audio...
