COSMO 1200
DESCRIPTION
Thank you for purchasing Hollyland Cosmo 1200 wireless high-definition video transmission
system. The product uses the latest wireless Transmission technology, and is widely used in
filmmaking, sports event and education industries. It transmits uncompressed, non-delayed HD
signals, with a transmission range of 1200ft.
KEY FEATURES
Broadcast level, Uncompressed, Non-delayed HD Video Transmission
350m/1200ft Transmission Range
5.1~5.9GHz Frequency Bandwidth. Frequency can be configured in different locations
Transmitter: SDI/HDMI In& SDI Loop Out, Receiver: Dual SDI&HDMI Out
Support 1 Transmitter with Multiple Receivers
Smart Colling Fan
Transmitter& Receiver Support External Batteries
7~36V DC Power Input
Support USB Firmware Upgrade
Stable and Reliable Industrial Metal Case
APPLICATION
Filmmaking
Sports Activities
Wedding Ceremonies
Corporate Events
1
Advertisement
Table of Contents
Related Manuals for Hollyland COSMO 1200
Summary of Contents for Hollyland COSMO 1200
- Page 1 COSMO 1200 DESCRIPTION Thank you for purchasing Hollyland Cosmo 1200 wireless high-definition video transmission system. The product uses the latest wireless Transmission technology, and is widely used in filmmaking, sports event and education industries. It transmits uncompressed, non-delayed HD signals, with a transmission range of 1200ft.
-
Page 2: Packing List
PACKING LIST 1.Receiver 2.Transmitter 3.5GHz Antenna 4.User Manual 5.7-inch Magic Arm 6.Crab Clamp 7.Mushroom Antenna 8.Mini USB Cable 9.DC/Lemo Conversion Cable... -
Page 3: Standard Setup
STANDARD SETUP The wireless high-definition video transmission system uses the latest wireless Transmission technology, and transmits broadcast- Level. uncompressed and non-delayed HD signals. The transmitter supports SDI&HDMI input and SDI loop-out, while the receiver supports dual SDI output and HDMI output. The transmitter works on a certain channel in broadcast mode, with a transmission distance of 350m/1200ft. - Page 4 Mushroom antennas are recommended to enhance stability performance of the system, especially when there is a big height difference between the transmitter and the receiver.
-
Page 5: Product Interfaces
PRODUCT INTERFACES (1) RECEIVER 1.1/4-20 Screw Hole 2.Mini USB Interface 3.HDMI Output 4.3G-SDI Output 1 5.3G-SDI Output 2 6.DC Power Switch 7.DC Power Input 8.OLED Screen 9.Channel Down 10.OK 11.Channel Up... -
Page 6: Oled Display
12.RP-SMA Male Antenna 13.3/8-16 Screw Hole (2) TRANSMITTER 1.1/4-20 Screw Hole 2.RP-SMA Male Antenna 3.Mini USB Interface 4.HDMI Input 5.3G-SDI Loop-out 6.3G-SDI Input 7.3.5mm Stereo In 8.DC Power Switch 9.DC Power Input 10.OLED Screen 11.Channel Up 12.OK 13.Channel Down 14.3/8-16 Screw Hole OLED DISPLAY 1. -
Page 7: Installation
INSTALLATION... - Page 8 1.Install the antennas with demonstrated angle of antennas for better performance 2.Mount the transmitter and the receiver 3.Connect to power supply 4.Turn on the devices 5.Transmitter Audio Input (Optional) 6.Pair the devices PARAMETERS Transmitter (TX) Receiver (RX) Interface SDI Input (BNC Female) SDI Output 1 SDI Loop Out (BNC Female) SDI Output 2...
- Page 9 Weight 260g 590g Size 126.5*70*25mm (L*W*H) 174*106*25mm (L*W*H) Antennas and battery plate Antennas and battery plate excluded excluded Video Input Format HDMI: 480P60, 576P50, 720P50/59.94/60, 1080I50/59.94/60, 1080P23.98/24/25/29.9/30/5 0/59.94/60 SDI: 3G, HD, and SD-SDI (Auto- Selected), SMPTE- 259/274/292/296/372/424/42 Video Output Format HDMI: 480P60, 576P50, 720P50/59.94/60,1080I50/59...
- Page 10 embedded in SDI Frequency Band 5.1-5.9GHz, 5.1-5.9GHz, configured to frequency band configured to frequency band for China, North America, for China, North America, Europe and etc. Europe and etc. Modulation Type OFDM-16QAM OFDM-16QAM RF Power Max. 19dBm Sensitivity -75dBm Bandwidth 40MHz 40MHz on the display...
