DESCRIPTION
Thank you for purchasing Hollyland Cosmo 1200 wireless high-definition video transmission system. The
product uses the latest wireless Transmission technology, and is widely used in filmmaking, sports event and
education industries. It transmits uncompressed, non-delayed HD signals, with a transmission range of 600ft.
KEY FEATURES
Uncompressed, non-delay wireless HD video transmission at the radio and television level
200 meters transmission Range
Frequency Band: 5.1~5.9GHz，Support different regional frequency configurations
SDI/HDMI input and SDI Loop out, Dual SDI output, HDMI output
Support one transmitter to transmit video, multiple receivers receive simultaneously
Both the transmitter and the receiver can mount the battery
7~36V DC Wide voltage input
Support USB interface software upgrade
Stable and reliable industrial metal casing
APPLICATION
Film shooting
Sports event
Wedding Ceremonies
Corporate Events
COSMO 600
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COSMO 600 and is the answer not in the manual?

Questions and answers

Related Manuals for Hollyland COSMO 600

Summary of Contents for Hollyland COSMO 600

  • Page 1 COSMO 600 DESCRIPTION Thank you for purchasing Hollyland Cosmo 1200 wireless high-definition video transmission system. The product uses the latest wireless Transmission technology, and is widely used in filmmaking, sports event and education industries. It transmits uncompressed, non-delayed HD signals, with a transmission range of 600ft.

  • Page 2: Packing List

    PACKING LIST 1.Receiver 2.Transmitter 3.5GHz Antenna 4.User manual 5.DC Conversion Cable 6.7-inch magic arm 7.Crab Clamp 8.Mushroom Antenna 9.USB cable...

  • Page 3: Standard Setup

    STANDARD SETUP The wireless high-definition video transmission system uses the latest wireless Transmission technology, and transmits broadcast- Level. uncompressed and non-delayed HD signals. The transmitter supports SDI&HDMI input and SDI loop-out, while the receiver supports dual SDI output and HDMI output. The transmitter works on a certain channel in broadcast mode, with a transmission distance of 600ft.
  • Page 4 This product includes mushroom antennas as accessory. When the height difference between the transmitter and the receiver is large, it is recommended to use a mushroom antenna to improve the stability of wireless transmission.

  • Page 5: Product Interfaces

    PRODUCT INTERFACES (1) Receiver 1.1/4-20 Screw hole 2.RP-SMA Antenna male interface 3.Mini USB interface 4.HDMI input interface 5.3G SDI Loop out interface 6.3G SDI Loop out interface 7.3.5mm Analog audio input interface 8.DC Power Switch 9.DC Power interface 10.OLED screen 11.Channel selection button 12.Frequency adjustment and confirm button Transmitter...

  • Page 6: Installation

    3.DC Power interface 4. Mini USB interface 5.HDMI input interface 6.3G SDI output interface 1 7.3G SDI output interface 2 8.OLED screen 9.Channel selection button 10.Frequency adjustment and confirm button 11.Channel subtract selection button 12.3/8-16 Screw hole 13.Channel subtract selection button 14.3/8-16 Screw hole INSTALLATION 1.Follow the picture instruction to install the antennas...

  • Page 7: Oled Display

    5.Connect the transmitter audio stereo in 6.Set up connection When the receiver does not receive the signal, the display shows the status of ‘No Video’, no format display OLED DISPLAY 1.RSSI indicator 2.Frequency display 3.Transmitter-signal source display，receiver-Video status display 4.Signal input/ output format display 5.Temperature reminder...
  • Page 8 When the connection is set up, the transmitter OLED menu display as below, ong press’MENU’ for 6 seconds to enter the function menu, display as below: 1.Version for the device programme. 2.Exit Menu When the connection is set up, the receiver OLED menu display as below, Long press ’MENU’...
  • Page 9 1.Version for the device programme. 2.OSD -- display the received signal quality 3.Exit Menu OSD MENU： Press DOWN button and move the selection to OSD enter the OSD menu. 4.OSD OFF-turn off the received signal quality display 5. OSD OFF- turn on the received signal quality display 6.RETURN to previous menu.
  • Page 10 selected),SMPTE- 259/274/292/296/372/424/425; Output Video HDMI: Format 480p60,576p50,720p50/59.94/60,108 0i50/59.94/60,1080p23.98/24/25/29.9 /30/50/59.94/60; SDI:3G,HD,and SD-SDI(auto- selected),SMPTE- 259/274/292/296/372/424/425; Input Audio SDI embedded 2 channel 24 Format bit/48KHZ Output Audio SDI embedded 2 channel 24 Format bit/48KHZ Frequency Band 5.1-5.9GHz， 5.1-5.9GHz， Configurable with China, North Configurable with China, North...
  • Page 11 4).Please check if battery power is too low. Poor output video quality 1).Check if SDI or HDMI input or output cable is plugged well 2).Make sure the Transmitter and Receiver are placed at least 1.5 meters above the ground 3).Please check the wireless signal strength indicating "RSSI" status. There should be at least 2-3 RSSI LED lit if the user wants to get better video quality.
