COSMO 2000
DESCRIPTION
Thank you for choosing Cosmo2000 Wireless HD Video Transmission System. Using the latest
wireless technologies, it can transmit wireless video with no compression and delay at a range of
2000ft and is widely used in film shooting, sport games, education market etc.
KEY FEATURES
Broadcast level uncompressed, non-delayed wireless HD video transmission
Transmit range 2000ft
5.1~5.9GHz frequency band, support different regional frequency configuration
SDI, HDMI input and SDI loop out, Dual SDI & HDMI output
Support one transmitter to multiple receivers
Built-in fan for heat dissipation
RX battery-mountable
7~36V DC Voltage input
USB software upgrade interface
Industrial metal case, stable and reliable
APPLICATION
Filmmaking
Sports Activities
Wedding Ceremonies
Corporate Events
1
Advertisement
Table of Contents
Related Manuals for Hollyland COSMO 2000
Summary of Contents for Hollyland COSMO 2000
- Page 1 COSMO 2000 DESCRIPTION Thank you for choosing Cosmo2000 Wireless HD Video Transmission System. Using the latest wireless technologies, it can transmit wireless video with no compression and delay at a range of 2000ft and is widely used in film shooting, sport games, education market etc.
-
Page 2: Packing List
PACKING LIST (1) 1*1 PACKING LIST 1.Receiver 2.Transmitter 3.5GHz Antenna 4.User Manual 5.7-inch Magic Arm 6.DC/Lemo Conversion Cable 7.Mushroom Antenna 8.Mini USB Cable 9.Crab Clamp... -
Page 3: Standard Setup
(2) 1*2 PACKING LIST 1.Receiver 2.Transmitter 3.5GHz Antenna 4.User Manual 5.7-inch Magic Arm 6.DC/Lemo Conversion Cable 7.Mushroom Antenna 8.Mini USB Cable STANDARD SETUP The wireless high-definition video transmission system uses the latest wireless Transmission technology, transmits broadcast-Level uncompressed, non-delayed HD signals. Transmitter supports SDI and HDMI input and SDI loop out. - Page 4 Mushroom antennas are recommended to enhance stability performance of the system, especially when there is a big height difference between the transmitter and the receiver.
-
Page 5: Product Interfaces
PRODUCT INTERFACES Transmitter 1.HDMI Input 2.3G-SDI Loop Out 3.3G-SDI Input 4.OLED Display 5.Frequency Channel Up 6.Frequency Confirm 7.Frequency Channel Down 8.3/8-16 Screw Hole 9.1/4-20Screw Hole 10.RP-SMA Antenna male interface 11.Mini USB Interface 12.3.5mm Analog Audio Input 13.DC Power Switch 14.DC Input 15.Smart Cooling Fan... - Page 6 (2) Receiver 1.Mini USB 2.HDMI Output 3.3G-SDI Output1 4.3G-SDI Output2 5.OLED Display 6.Frequency Channel Up 7.Frequency Confirm/Menu 8.Frequency Channel Down 9.DC Power Switch 10.DC Power Input 11.RP-SMA Antenna male interface 12.3/8-16 Screw Hole 13.Smart Cooling Fan 14.1/4-20 Screw Hole...
-
Page 7: Installation
INSTALLATION 1.Follow the picture instruction to install the antennas 2.Stabilize the transmitter and receiver 3.Connect power supply 4.Turn “ON” the switch. -
Page 8: Oled Display
5. Connect the transmitter audio stereo in 6. Set up connection When the receiver does not receive the signal, the display shows the status of ‘No Video’, no format display OLED DISPLAY 1.RSSI indicator 2.Frequency display 3.Transmitter -Source Signal Display，receiver -Video Status Display 4.Signal input/ output Format 5.Temperature reminder 6.Temperature Display... - Page 9 Transmitter Fan Function Press MENU button for 6 seconds to enter menu, select “ADVANCED” to enter TX fan option. 1.“BASIC MODE ”-Turn off replay without delay function, smart cooling fan and reduce power consumption 2.“SMART MODE ”-Turn on replay without delay function, turn on or off smart cooling fan automatically according to temperature 3.“RETURN”- back Transmitter Encryption Pair Function...
- Page 10 Transmitter Smart Cooling Fan and Encryption Pair Selection 1.Long press “MENU” button, enter into “SECURITY” menu, select “ENABLE”, transmitter start encryption pairing...
- Page 11 2.After successfully paired, single press transmitter “MENU” button to exit pairing and return to main menu interface, restart receiver. PRODUCT INSTALLATION and CHECK Receiver Scan Channel and Wireless Signal Strength Indication Press receiver “MENU” button for 6 seconds, enter main menu 1.“SCAN CHANNEL”-Auto scan channel function 2.“RSSI OPTION”--Received signal strength indication 3.“SECURITY”-Encryption, decryption and device ID check...
- Page 12 Receiver “Received Signal Strength Indication” Introduction Disable encryption on receiver main menu and single press to select “RSSI OPTION，the display will show the quality of signal received by the 5 antennas. Note：Value of I and Q the bigger the better, value of P the smaller the better. PARAMETERS Transmitter(TX) Receiver(RX)
- Page 13 9/30/50/59.94/60; SDI: 3G, HD, and SD-SDI(auto- selected),SMPTE- 259/274/292/296/372/424/425; Output Video HDMI: Format 480p60,576p50,720p50/59.94/60,10 80i50/59.94/60,1080p23.98/24/25/29. 9/30/50/59.94/60; SDI: 3G,HD,and SD-SDI(auto- selected),SMPTE- 259/274/292/296/372/424/425; Input Audio SDI embedded 2 channel 24 bit/48KHz Output Audio SDI embedded 2 channel 24 bit/48KHz Frequency Band 5.1-5.9GHz, configurable with China, 5.1-5.9GHz, configurable with China, North America, Europe and etc.
- Page 14 No video output on display 1).Please check TX and RX power first. If power is supplied by battery or external power source, please make sure the battery or external power source works normally. 2).Please check that the antenna connected to the transmitter and receiver is securely mounted. 3).Then check if the transmitter shows the source and format;...
