Operating Safety Guidelines.........................11 Getting Started..............................12 Identifying Components.........................12 Setting up Your VisionPlate ........................16 Mobile Use..............................20 Powering the VisionPlate On and Off ....................22 Using the Stylus ............................24 Battery Use and Maintenance......................26 Using Your VisionPlate with Embedded Linux................28 Touchscreen Calibration .........................28 Adjusting the Brightness of the LCD....................29 Adjusting the Volume ..........................30...
Page 5
3.10 Programmable Button ..........................38 Using Your VisionPlate with Windows XP embedded.............40 Windows Toolbar Overview........................40 Touchscreen Calibration .........................41 Adjusting the Brightness of the LCD....................43 Adjusting the Volume ..........................43 Prolonging Battery Life and Instant on/off Functionality............44 Low Battery Notification Settings ......................46 Installing and Removing PC Cards......................47 Installing and Removing Compact Flash (CF) Cards ..............49...
Page 6
However, due to continuous efforts being made to improve and update the VisionPlate product, Hitachi Data Systems shall not be liable for any technical or editorial errors or omissions contained in this document, or for any damage, direct or indirect, from discrepancies between this document and the products it describes.
If you have additional questions about your product and how to operate it in a safe manner, please contact your Hitachi Customer Service or an authorized Support Representative.
1.3 Vision Risk Factors Sustained viewing of screens can lead to fatigue, blurred or double vision, and headaches. Some researchers believe that users who look at their screens for long durations can even undergo changes in how clearly and quickly they focus. 1.3.1 Things to Keep in Mind •...
Hitachi Customer Service and Support Representative. 1.6.1 Things to Keep in Mind • Never remove the cover or back panel of your Hitachi Data Systems product unless you have been instructed to do so by a Hitachi Customer Service or an authorized Support Representative.
• When disposing of the battery pack, cover the metal terminals with a non-conducting tape to prevent accidental short-circuiting. • Use the battery pack supplied with the Hitachi Data Systems product only, as other battery packs could be incompatible with the Hitachi Data Systems product and could damage the product.
California to cause cancer, and birth defects or other reproductive harm. 1.9 AC Adapter Guidelines Using any power source other than the Hitachi Data Systems AC adapter or power cord that comes with your product could result in exposure to electric shock hazards.
1.11 Liquid Crystal Display (LCD) Guidelines If the VisionPlate’s LCD is damaged, the liquid contained within the display could leak. Any ingestion of this liquid can result in serious bodily injury or illness. 1.11.1 Things to Keep in Mind •...
1.12 Proper Treatment of Your Hitachi Product Allowing any metal objects, such as screws or paper clips, to fall into the VisionPlate could result in a short circuit, fire, or other internal damage. To avoid serious damage, never allow any liquids to spill into any part of your Hitachi product and never expose the product to rain or other liquids when the peripheral covers are open.
1.13 Safety and Regulatory Compliance 1.13.1 FCC Part 15 Compliance Statement Note: This equipment has been tested and found to comply with limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 15
WARNING: Do not connect or disconnect all connectors unless the work area is known to be nonhazardous. • The AC adapter and Cradle for the VisionPlate are not listed for use in Class I, Division 2, Group A, B, C and D Hazardous Locations.
1.14 General Safety Guidelines • Follow all cautions and instructions marked on the product. • Ensure that the operating voltage of your product is the same as the voltage of your local power supply. Otherwise, there is a risk of damage or electrical shock or fire. If voltage adaptation is required, consult your place of purchase.
50 to 60 cm (20 to 24 inches). • Adjust the brightness of your display and the room lighting to prevent any reflection or glare on the display. • Avoid exhaustion by taking frequent breaks. Hitachi VisionPlate User Manual...
2 Getting Started Thank you and congratulations on the purchase of your Hitachi VisionPlate wireless tablet. This section describes how to set up your VisionPlate and how to turn the VisionPlate on and off. 2.1 Identifying Components The following illustration shows the front panel of your VisionPlate:...
Page 19
Solid Green Charged battery Blinking Red Low battery Sufficient charge Power Button/Power Lamp Solid Green In operation Blinking Green Power saving mode 2.1.2 Left Side Connectors The following illustration shows the left side connectors: PC card slot Hitachi VisionPlate User Manual...
Page 20
2.1.3 Right Side Connectors The following illustration shows the right side connectors: CF card slot Headphone connector Microphone connector USB interface connectors (x2) Power supply connector Chapter...
Page 21
2.1.4 Cradle (optional) The following illustration shows the optional Cradle: USB interface connectors Power supply connector Stylus holder Stand Hitachi VisionPlate User Manual...
2.2.1 Direct to Outlet Connection Plug the AC adapter into the Power supply connector, which is located on the right side of the VisionPlate, with the directional arrow facing down, as shown in the following illustration: AC adapter Power supply connector...
Page 23
AC adapter Cradle 2. Open the Cradle interface cover (located on the bottom of the VisionPlate), and verify that it extends downward from the VisionPlate so as not to interfere with the docking connector. Hitachi VisionPlate User Manual...
Page 24
3. Slide your VisionPlate into the Cradle, as shown in the following illustration: Note: The angle of the Cradle can be adjusted by loosening the two screws on the bottom of the stand, as shown in the following illustration: Chapter...
Page 25
1. Remove the base of the Cradle by removing the two screws, as shown in the following illustration: 2. Fasten the top portion of the Cradle to the VESA compliant mounting stand as shown in the following illustration: Hitachi VisionPlate User Manual...
The VisionPlate comes with a lithium ion battery pack that can be used for mobile applications. When your VisionPlate is powered on with the battery pack installed for the first time, an AC adapter must be plugged in to fully charge the battery.
Page 27
3. Replace the battery cover, and then fasten the screws, as shown in the following illustration: Hitachi VisionPlate User Manual...
This section describes how to turn the power to the VisionPlate on and off. 2.4.1 Powering the VisionPlate On To turn the VisionPlate on, press the Power button, as shown in the following illustration: Power button 2.4.2 Powering the VisionPlate Off For Linux versions, tap the Menu icon, tap System, and then tap Shutdown, as shown in the following illustration.
Page 29
Important: Unplug the AC cord when your VisionPlate is not used for an extended period of time. Hitachi VisionPlate User Manual...
1.5 Using the Stylus The stylus is used to operate the VisionPlate. The stylus has three basic actions, which are described in this section. Single tap: Single tapping involves touching the screen softly with the stylus_This action is the same as a single click of the left button of a mouse, and is used to select an item.
Page 31
Right click functionality: For embedded Windows environments, the VisionPlate provides a right click tool. This tool provides right click functionality without the use of a mouse, enabling use of right click functions in a mobile environment. The right click menu is displayed when the stylus is held down on the touchscreen for approximately one second.
2.6 Battery Use and Maintenance 2.6.1 Charging the Battery Pack Your VisionPlate comes with a lithium ion battery pack, which is not fully charged. You must fully charge the battery before you use your VisionPlate. The battery is charged by attaching a battery pack to your VisionPlate, connecting the AC adapter to the VisionPlate, and then plugging the AC adapter into an electrical outlet.
To properly maintain your batteries, keep the following guidelines in mind: • The battery will discharge slowly if it is attached to the VisionPlate without an AC adapter for an extended period of time. A fully discharged battery will take a longer time to charge and can have reduced capacity.
3 Using Your VisionPlate with Embedded Linux Your VisionPlate comes pre-installed with an embedded Linux operating system or an embedded Microsoft Windows XP operating system. This section describes the basic functionality of pre- installed Linux models. 3.1 Touchscreen Calibration To calibrate the touchscreen, do the following: 1.
To adjust the brightness of the LCD screen, do the following: Using the stylus, tap the Menu icon , tap Settings, then tap Brightness, as shown in the following illustration: 2. Move the slide bar to adjust the brightness. 3. Tap OK. Hitachi VisionPlate User Manual...
3.3 Adjusting the Volume To adjust the volume of your VisionPlate, do the following: Using the stylus, tap the Menu icon , tap Settings, then tap Volume, as shown in the following illustration: 2. Move the slide bar to adjust the volume.
The Power button and Time-out function can be used to prolong battery life. 3.4.1 Power Button If the Power button is firmly pressed and released, your VisionPlate will enter one of three power modes. Enter Low Power Mode: Your VisionPlate will enter Low Power Mode.
Your VisionPlate will notify you when your battery level is low. There are three user-selectable methods of notification, as follows: Audible Warning: The VisionPlate will beep when the battery level is low, until the AC adapter is connected. Popup Message: The VisionPlate will display a popup message notifying you of the low battery condition.
You can remove a PC card only when the card is in Stop status. To remove a PC card, do the following: Caution: You can cause damage to the PC card if you remove the PC card while the VisionPlate is in use.
Note: If it is difficult to remove the PC card, press the PC card back in and then press the Eject button again. 3.7 Installing and Removing Compact Flash (CF) Cards The VisionPlate supports one Type I or Type II CF card. 3.7.1 Installing a CF Card To install a CF card, do the following: 1.
You can remove a CF card only when the card is in a Stop status. To remove a CF card, do the following: Caution: You can cause damage to the CF card if you remove CF card while the VisionPlate is in use.
5. Press the Eject button to remove the CF card, as shown in the following illustration: 3.8 Wireless LAN Configuration Your wireless LAN can be configured as follows: Using the stylus tap on the tool icon on the control bar. The Network tab should be selected as default.
3.9 Screen Rotation The VisionPlate supports screen rotation for Linux environments. A screen rotation tool is provided to enable you to select 90 degree or 270 degree states that can be directly accessed by...
3.10 Programmable Button The VisionPlate includes a Programmable button that is located just under the Power button. In embedded Linux systems this button can be programmed to launch applications or run custom programs.
4 Using Your VisionPlate with Windows XP embedded Your VisionPlate comes pre-installed with an embedded Linux operating system or a Microsoft Windows XP embedded operating system. This section describes basic functionality of pre-installed Microsoft XP embedded models. 4.1 Windows Toolbar Overview The Windows toolbar for Microsoft Windows XP embedded has four distinct areas: The Start Menu area, the Quick Launch area, the Active window area, and the Notification area.
+ mark will appear at the top center of the screen. Tap the center of this second + mark. Repeat this process for a total of 12 times as the + mark moves to the bottom right of the screen. Tap here Hitachi VisionPlate User Manual...
Page 48
Tap the Calibration Button, which will be active as shown in the following illustration: The Control page will appear, as shown in the following illustration. Tap the Save and Exit button. Note: If the calibration tool cannot be accessed using the stylus, due to excessive calibration offset, a USB mouse can be used instead of the stylus to access the calibration tool.
2. Move the slide bar to adjust the brightness. 3. Tap OK. 4.4 Adjusting the Volume To adjust the volume of your VisionPlate, do the following: Using the stylus, double tap the volume icon in the task bar Notification Area. The following window will appear.
4.5 Prolonging Battery Life and Instant on/off Functionality The VisionPlate provides the option of setting a Low Power Mode for prolonging battery life and for Instant on/off functionality. The Power button and Time-out function can be used to prolong battery life.
Page 51
4.5.2 Time-out The VisionPlate can be programmed to enter various low states of power by turning off any combination of the monitor, the compact flash storage device, and the CPU. This time-out period for each option can be changed by following these steps: 1.
3. Tap the Alarm tab. The following menu will appear: 4. There are four user-selectable methods of notification, as follows: Sound Alarm: The VisionPlate will beep when the battery level is low. To enable this mode, check the Sound alarm box.
You can remove a PC card only when the card is in Stop status. To remove a PC card, do the following: Caution: You can cause damage to the PC card if you remove the PC card while the VisionPlate is in use.
Page 54
2. Highlight the icon for the device you want to remove, then tap the Stop button. 3. Tap OK. 4. Open the cover of the PC card slot. 5. Press the Eject button to remove the PC card, as shown in the following illustration: Note: If it is difficult to remove the PC card, press the PC card back in and then press the Eject button again.
You can remove a CF card only when the card is in a Stop status. To remove a CF card, do the following: Caution: You can cause damage to the CF card if you remove CF card while the VisionPlate is in use.
Page 56
2. Highlight the icon for the device you want to remove, then tap the Stop button. 3. Tap OK. 4. Open the cover of the CF card slot. 5. Press the Eject button to remove the CF card, as shown in the following illustration: Chapter...
4.10 Programmable Button The VisionPlate includes a Programmable button, which is located just under the Power button. This button can be programmed to launch applications or run custom programs. The Hitachi team is available for programming and customization services as well as development support and assistance.
-commitanddisable Save RAM cache data to Compact Flash and disable Note: If the EWF is not executed before your VisionPlate is shut down, all changes and modifications made to the VisionPlate, including application installs, network setting changes, and bookmark modifications, will not be in effect upon rebooting.
When troubleshooting the display, follow these guidelines. If there is no display, do the following: • Verify that the VisionPlate is not in Low Power or Standby mode. Touch the screen or press the Power button for one second. • Ensure that the AC cord and the AC adapter are plugged in correctly.
6 Specifications PC5NR3-J9xxxxxxxx PC5NR3-Z9xxxxxxxx Operating System (embedded) Midori Linux Windows XPe Transmeta Crusoe™ Processor TM5500 667MHz Cache Memory Primary 128kB CPU Embedded Secondary 256kB CPU Embedded Main Memory Capacity Standard 128MB, Max 256MB Transmissive 10.4" TFT, 800x600 (SVGA), or 1024x768 (XGA), 262144 Display color, indoor viewable VRAM...
Page 61
VisionPlate User Manual September 2003 Hitachi Data Systems Ubiquitous Business Solutions 750 Central Expressway Santa Clara, CA 95050 V2.0 Hitachi VisionPlate User Manual...
