Page 1: User Manual
LP-TS200 CW LP-TS200 WW User Manual Please read the instruction carefully before use... -
Page 2: Table Of Contents
CONTENTS 1. Safety Instructions ..................2 2. Technical Specifications .................. 4 3. Accessories ..................... 5 4. The Plate for Color Filter & Barn Door Installation ......... 6 5. How To Set The Unit ..................7 5.1 Control panel .................... 7 5.2 Main Functions .................. -
Page 3: Safety Instructions
1. Safety Instructions Please read the instruction carefully, it includes important information about the installation, usage and maintenance. WARNING Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. ... - Page 4 Please make sure there are no flammable materials close to the unit while operating, as it is fire hazard. Please look over power wires carefully, replace immediately if there is any damage. Never run on for a long time lest shortening lifespan. ...
-
Page 5: Technical Specifications
Focus: Automatic focus by DMX control Dimmer: 0 ~ 100% Beam Angle: 12 ° ~ 40 ° Color Temperature: 5600+200K (LP-TS200 CW) 3200+200K (LP-TS200 WW) Rotating filter and hanger Thermo-optical cooling technology with quiet ... -
Page 6: Accessories
Photometric Diagram: 3. Accessories Standard Accessories Simple Bracket Optional Accessories Adjustable Bracket... -
Page 7: The Plate For Color Filter & Barn Door Installation
4. The Plate for Color Filter & Barn Door Installation Fig 1 ○ At first, please push the Lock Cap by hand as the arrow , and move away the Lock as the ○ arrow ; Then insert the Plate for Color Filter into the inside slot from topside; Fig 2 ○... -
Page 8: How To Set The Unit
5. How To Set The Unit 5.1 Control panel 11 12 1. Display: Show the various menus and the selected functions 2. LED: DMX input present POWER Power On 3. Button: MENU To select the programming functions DOWN To go backward in the selected functions To go forward in the selected functions ENTER To confirm the selected functions... -
Page 9: Main Functions
8. Power Cable: Used to connect the main power supply. 9. DMX input: For DMX512 link, use 5-pin XLR cable to link the unit together. 10. DMX output: For DMX512 link, use 5-pin XLR cable to link the unit together. 11/12. -
Page 10: Dmx Address
DMX Address Select DMX Address, press the ENTER button to confirm, the present address will blink on the display. Use the UP and DOWN button to adjust the DMX address from 1 to 512. Once the address has been selected, press the ENTER button to save. Hold and press the MENU button about one second or wait for one minute to exit the menu mode. -
Page 11: Slave Mode
Slave Mode Select Slave Mode, press the ENTER button to confirm, present mode will blink on the display. Use the DOWN and UP button to select the Master or Slave mode. Once the mode has been selected, press the ENTER button to save. Hold and press the MENU button about one second or wait for one minute to exit the menu mode. - Page 12 Display Inverse Select Display Inverse, press the ENTER button to confirm, present mode will blink on the display, use the UP/DOWN button to select the No (normal display) or Yes (inverse display), press the ENTER button to save. Press the MENU button back to the last menu or let the unit idle one minute to exit menu mode.
-
Page 13: How To Control The Unit
Firmware Version Select Firmware Version, press the ENTER button to confirm, the software version will show on the display. Press the MENU button back to exit. Factory Setting Select Factory Setting, press the ENTER button to confirm, present mode will blink on the display. Use the DOWN and UP button to select the No or Yes (Switch back to default settings). -
Page 14: Dmx 512 Configurations
Unit 1 Unit 2 Unit 3 Unit 4 Channel Mode Address Address Address Address 2 Channels 6.3 DMX 512 Configurations 2 Channels Mode: 7. DMX 512 Connections The DMX512 is widely used in intelligent lighting control, with a maximum of 512 channels. output... -
Page 15: Troubleshooting
1. Connect the fixture together in a “daisy chain” by XLR plug cable from the output of the fixture to the input of the next fixture. The cable cannot be branched or split to a “Y” cable. Inadequate or damaged cables, soldered joints or corroded connectors can easily distort the signal and shut down the system 2. -
Page 16: Fixture Cleaning
DMX polarity. 3. If you have intermittent DMX signal problems, check the pins on connectors or on PCB of the unit or the previous one. 4. Try to use another DMX controller. 5. Check if the DMX cables run near or run alongside to high voltage cables that may cause damage or interference to DMX interface circuit. - Page 17 D eclaration of Conformity We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 89/336/EEC. EN55103-1: 2009 ; EN55103-2: 2009; EN62471: 2008; EN61000-3-2: 2006 + A1:2009 + A2:2009; EN61000-3-3: 2008. &...
