    LP-F2000 VW User Manual Please read the instructions carefully before use...
  • Page 2: Table Of Contents

    CONTENTS 1. Safety Introductions ....................2 2. Technical Specifications ..................3 3. How To Set The Fixture ..................4 3.1 Control Panel ....................4 3. 2 The Plate for Barn Door Installation ............... 5 4. How To Control The Unit ..................10 4.1 Master/Slave Function ..................
  • Page 3: Safety Introductions

    1. Safety Introductions Please read the instructions carefully which includes important information about the installation, operation and maintenance. WARNING Please keep this User Manual for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. ...
  • Page 4: Technical Specifications

    Caution: There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact your nearest dealer. Installation: The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating.
  • Page 5: How To Set The Fixture

    127.5 147.5 3. How To Set The Fixture 3.1 Control Panel 1. ETHERNET: Connect with the multimedia and use software to control the units via ArtNet; 2. DMX IN/OUT : For DMX 512 link, use 5-pin XLR cable to link the unit to a DMX controller or the next unit and output DMX signal;...
  • Page 6: The Plate For Barn Door Installation

    ENTER To confirm the selected functions 9. Display: Shows the various menus and the selected functions. 3. 2 The Plate for Barn Door Installation At first, please push the barn door by hand. Screw Secondly, please put the Barn Door into the unit, to fasten the screws of the slot, then finish the barn door installation.
  • Page 7 DMX Address IP Address DMX Setting rt-Net Setup Sub-Net Universe 2 Channel A hannel Channel Mode B hannel 4 ha nel 5 Cha nel 6 ha nel Favt DimmOr SpOOd Smooth Linear Curve Square Law Curve Dimmer Curve Invert Square Law Curve S Curve Master Slave Mode...
  • Page 8 DMX Setting Select the DMX Setting, press the ENTER button to confirm. Use the UP and DOWN button to select DMX Address, Art-Net Setup or Channel Mode. DMX Address Select the DMX Address, press the ENTER button to confirm, the display will show the present address.
  • Page 9 Mode 1(Optically Linear): The increase in light intensity appears to be linear as DMX value is increased. Mode 2(Square Law): Light intensity control is finer at low levels and coarser at high levels. Mode 3(Inverse Square Law): Light intensity control is coarser at low levels and finger at high levels. Mode 4(S-cure): Light intensity control is finger at low levels and high levels and coarser at medium levels.
  • Page 10 Contrast Ratio, Backlight Auto off ,Display Inverse or Language. Contrast Ratio Select Contrast Ratio, press the ENTER button to confirm, the present mode will blink on the display, use the UP and DOWN button to adjust from 1 to 30, press the ENTER button to store. Press the MENU button back to the last menu or idling 30 seconds to exit menu mode.
  • Page 11: How To Control The Unit

    Select Fixture Time, press the ENTER button and the display will show the number of working hours of the unit. To go back to the functions press the MENU button again. Firmware Version Select Firmware Version, press the ENTER button and the display will show the version of firmware of the unit.
  • Page 12: Dmx512 Configuration

    1 to 512, press the ENTER button to store. Press the MENU button back to the last menu or let the unit idle one minute to exit menu mode. Please refer to the following diagram to set the address for the first 4 units. Unit 1 Unit 2 Unit 3...
  • Page 13 3B Channel Mode: CHANNEL VALUE FUNCTIONS COLOR TEMPERATURE 001 ~ 255 5600K~3200K DIMMER 000 ~ 255 0  100% DIMMER FINE 000 ~ 255 0  100% 4 Channel Mode: CHANNEL VALUE FUNCTIONS WW DIMMER 000 ~ 255 0  100% CW DIMMER 000 ~ 255 0 ...
  • Page 14 DIMMER FINE 000 ~ 255 0  100% 6 Channel Mode: CHANNEL VALUE FUNCTIONS WW DIMMER 000 ~ 255 0  100% CW DIMMER 000 ~ 255 0  100% COLOR TEMPERATURE 001 ~ 255 5600K~3200K STROBE 000-031 032-063 064-095 Strobe: Slow ...
  • Page 15: Dmx512 Connections

    4.4. DMX512 Connections The DMX512 is widely used in intelligent lighting control, with a maximum of 512 channels. 1. At last unit, the DMX cable has to be terminated with a terminator. Solder a 120-ohm 1/4W resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug and plug it in the DMX-output of the last unit.
  • Page 16: Troubleshooting

    5. Troubleshooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The fixture does not work, no light 1. Check the connection of power and main fuse. 2. Measure the mains voltage on the main connector. B.
  • Page 19: Declaration Of Conformity

    Declaration of Conformity We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 89/336/EEC. EN55103-1: 2009+A1:2012; EN55103-2: 2009; EN61000-3-2: 2014; EN61000-3-3: 2013. & Harmonized Standard EN 60598-1:2015;...
