- Page 1 MANUAL ENGLISH Compact 6.2 Ordercode: D2320 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Compact 6.2 Table of contents Warning ................................... 2 Safety Instructions ..............................2 Operating Determinations ............................4 Connection with the mains ............................. 4 Return Procedure ..............................4 Claims ..................................4 Description of the device ............................. 5 Features ..................................5 Frontside ..................................5 Backside .................................. -
Page 3: Warning
Compact 6.2 Warning Unpacking Instructions Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure that all parts are present and have been received in good condition. Notify the dealer immediately and retain packing material for inspection if any parts appear damaged from shipping or the carton itself shows signs of mishandling. - Page 4 Compact 6.2 IMPORTANT: The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual or any unauthorized modification to the system. Never let the power cord come into contact with other cables! Handle the power cord and all connections with the mains with particular caution! ...
-
Page 5: Operating Determinations
Compact 6.2 Operating Determinations This system is not designed for permanent operation. Consistent operation breaks will ensure that the system will serve you for a long time without defects. If this system is operated in any other way, than the one described in this manual, the product may suffer damages and the warranty becomes void. -
Page 6: Description Of The Device
Compact 6.2 Description of the device Features 6 Channel 1U mixer/USB player The Compact 6.2 is the ideal mixer for sports instructors. It is equipped with 2 microphone inputs with built- in compressor limiters and high-pass filters. This will help the instructor to keep perfect intelligibility, as the dynamic range will be extended and distortion will be eliminated. - Page 7 Compact 6.2 Peak LED (Stereo Input) The peak LED shows signal peaks in a channel’s incoming signal. If the red peak LED frequently blinks or constantly lights up, the corresponding channel is likely to enter clipping. Make sure that the peak LED lights up only briefly, during dynamic peaks. USB A connector –...
-
Page 8: Backside
Compact 6.2 Backside Fig. 02 Power adapter connector The remote AC power supply. Use only the supplied DAP Audio adapter. Master Equalizer The output equalizer allows to shape the outcoming audio signal. The high and low shelving controls have their frequencies fixed at 12kHz and 80Hz, respectively. The mid-range control has a peaking response frequency at 2,5kHz. -
Page 9: Installation
Compact 6.2 Threshold control Turn the control to set the threshold of compression. Ratio/Compressor control Turn the control to adjust the ratio of the compressor. Installation Remove all packing materials from the Compact 6.2. Check that all foam and plastic padding is removed. -
Page 10: Repeat Function
Compact 6.2 Repeat Function 01) Repeatedly press the SINGLE button (11) to toggle between the following playback modes: A – Once the final track from a given folder has passed, the player will skip to the following folder, starting playback from the first track on the list. ... -
Page 11: Connection Cables
Compact 6.2 Connection Cables Take care of your cables, always holding them by the connectors and avoiding knots and twists when coiling them: This gives the advantage of increasing their life and reliability. Periodically check your cables. A great number of problems (faulty contacts, ground hum, discharges, etc.) are caused entirely by using unsuitable or faulty cables. -
Page 12: Connection Example
Compact 6.2 Connection Example Fig. 03 Ordercode: D2320... -
Page 13: Maintenance
Compact 6.2 Maintenance The DAP Audio Compact 6.2 requires almost no maintenance. However, you should keep the unit clean. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. Do not use alcohol or solvents. Keep connections clean. -
Page 14: Notes
Compact 6.2 Notes Ordercode: D2320... - Page 15 Compact 6.2 Ordercode: D2320...
- Page 16 ©2016 DAP Audio...
