- Page 1 MANUAL ENGLISH Core Scratch Ordercode: D2312 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Core Scratch Table of contents Warning ....................................2 Unpacking Instructions ..............................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Overview ..................................... 4 Microphone channel ..............................5 Monitor section ................................5 Main channels ................................6 Master section ................................7 Bluetooth section ................................7 Rear ...................................... -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: DAP Audio Core Scratch AC Power adapter ... - Page 4 Core Scratch IMPORTANT: The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual or any unauthorized modification to the system. Never let the power-cord come into contact with other cables! Handle the power-cord and all connections with the mains with particular caution! ...
-
Page 5: Operating Determinations
Core Scratch Operating Determinations This device is not designed for permanent operation. Consistent operation breaks will ensure that the device will serve you for a long time without defects. The minimum distance between light-output and the illuminated surface must be more than 0.5 meter. - Page 6 Core Scratch Microphone channel Mic input Connect a microphone here. Level control Adjusts the sound level output from the MIC channel. High control The High control adjusts the High frequency range. Range: -26dB to +12dB at 10kHz. Low control The Low control adjusts the Low frequency range.
- Page 7 Core Scratch Main channels Selection switch (Line (31)/Line (32)) Assign Line (31) or Line (32) to Channel 1. Selection switch (Line (28)/Line (29)) Assign Line (28) or Line (29) to Channel 2. Gain control Adjusts the level of the audio signal input in each channel.
- Page 8 Bluetooth device. Bluetooth connectivity LED Displays the status of the Bluetooth connectivity. When the LED is blinking, the device is in matching state. When the light is constantly on, a device is connected to the Core Scratch mixer. D2312...
-
Page 9: Rear
Core Scratch Rear AC adapter inlet Channel 2 RCA unbalanced input Connects to a power outlet using the Connect to a DJ player or a line level output included AC power adapter. component. Power switch Line – Bluetooth switch Turns this unit’s power on and off. -
Page 10: Connection Example
Core Scratch Connection Example D2312... -
Page 11: Connection Cables
Core Scratch Connection Cables Take care of your cables, always holding them by the connectors and avoiding knots and twists when coiling them: This gives the advantage of increasing their life and reliability. Periodically check your cables. A great number of problems (faulty contacts, ground hum, discharges, etc.) are caused entirely by using unsuitable or faulty cables. -
Page 12: Connect A Bluetooth Device
To connect to a different Bluetooth device, repeat steps 4-5. Maintenance The Dap Audio Core Scratch requires almost no maintenance. However, you should keep the unit clean. Disconnect the mains power supply and then wipe the cover with a damp cloth. Do not immerse in liquid. -
Page 13: Product Specifications
Core Scratch Product Specifications Model: DAP Audio Core Scratch Input Channels: 1x Microphone, combo XLR/Jack 4x Line RCA 1x Bluetooth Output channels: 1x Record, RCA 1x Booth, RCA 1x Master unbalanced, RCA 1x Headphones, TRS 6.3mm Jack Channel EQ: High frequency:... -
Page 14: Dimensions
Core Scratch Dimensions D2312... -
Page 15: Notes
Core Scratch Notes D2312... - Page 16 ©2013 DAP Audio...
