3. INSTALLATION

3-15. Installing the machine head fixing bolt

When transporting the sewing machine, secure the machine head to the table with the machine head fixing bolt.

3052B

3053B

1. Turn on the power switch.

2. Check that no error numbers appear on the operation panel.

If the machine head switch (1) is not turned on, error [E050],

[E051] or [E055] will occur.

Use the screw (2) to adjust the installation position of the

machine head switch as shown in the illustration.

3054B

BAS-311H

(1) Plain washer [2 pcs.]

(2) Machine head fixing bolts [2 pcs.]

NOTE:

When operating the sewing machine,

remove the machine head fixing bolt.

(1) Bobbin winder tension

(2) Set screw [1 pc.]
