8 • Media System w/Advanced Image Processing: Adagio AMS-AIP
AMS-AIP Specifications (Continued)
SPECIFICATION
Audio – Surround Sound
Processor (continued)
Total Harmonic Distortion (THD)
+ Noise
Signal-to-Noise Ratio (SNR)
Dynamic Range
Channel Separation
Audio – Multi Room Distribution
(Typical of up to 5 Stereo, or 4
Stereo + 2 Mono Room Outputs)
Controls
Volume Gain Range
Mute
Input Compensation
Bass Gain Range
Treble Gain Range
Frequency Response
Signal-to-Noise Ratio (SNR)
Total Harmonic Distortion (THD)
+ Noise
Stereo Separation
Power
Internal Power Supply
AMS-AIP/
AMS-AIP-XM/
AMS-AIP-SR
AMSI-AIP
Available Cresnet Power
LCD Display
Environmental
Temperature
Humidity
2
Heat Dissipation
8-ohm impedance
4-ohm impedance
Enclosure
(Continued on following page)
Crestron Adagio
DETAILS
<0.006% (preamp), 0.03% (power amp)
20Hz to 20kHz
>100dB (preamp), 100dB (power amp) 20Hz
to 20kHz A-weighted
>113dB
>85dB (preamp), >80dB (power amp)
Volume, Balance, Bass, Treble, Loudness,
Mute, Mono, Input Compensation
-80dB to +20dB, 1 dB steps
-100dB (electronic), -120dB (relay/room off)
±10dB, 1db steps
±12dB, 2dB steps
±12dB, 2dB steps
20Hz to 20kHz ±0.4dB
>100dB 20Hz to 20kHz A-weighted
<0.08% 20Hz to 20kHz
>75dB
1000 Watts (8 Amps) @ 120 Volts AC,
50-60Hz
1000 Watts (4 Amps) @ 220-240 Volts AC,
50-60Hz
20 Watts (0.83 Amps @ 24 Volts DC)
Green LCD dot matrix, 128 x 64 resolution,
adjustable LED backlight
41° to 104°F (5° to 40°C)
10% to 90% RH (non-condensing)
1600 BTU/hr
2000 BTU/hr
Black metal with molded ABS/PC front
panel;
Freestanding, side ventilation should not be
restricted
Operations Guide – DOC. 6516B
®
AMS-AIP
