  • Page 1 Crestron Adagio AMS-AIP ® Media System with Advanced Image Processing Operations Guide...

  • Page 2: Important Safety Instructions

    • Prevent foreign objects from entering the device. All brand names, product names and trademarks are the property of their respective owners. ©2008 Crestron Electronics, Inc.

  • Page 3: Table Of Contents

    ® Crestron Adagio AMS-AIP Media System w/Advanced Image Processing Contents Media System with Advanced Image Processing: Adagio AMS-AIP Introduction ..........................1 Features and Functions ....................1 Advanced Image Processing .................2 HDMI™ and DVI Technology ..............2 7.1 Surround Sound..................2 High-End Audio Performance...............2 ®...
  • Page 4 Programming Software ......................108 Earliest Version Software Requirements for the PC ..........108 Programming with Adagio Composer ..............108 Programming with Crestron SystemBuilder............108 Programming with SIMPL Windows ..............109 Programming with VisionTools Pro-e..............109 Configuring the AMS-AIP ..................110 Switching Programs....................

  • Page 5: Media System With Advanced Image Processing: Adagio Ams-Aip

    AMS-AIP provides sophisticated surround processing, amplification, and digital video processing for a complete home theater, plus audio signal routing for four or more pairs of remote room speakers. Its built-in Crestron control system enables enhanced control and integration capability for AV and home automation.

  • Page 6: Advanced Image Processing

    MultEQ XT is the only technology of its kind capable 2 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...

  • Page 7: Av Inputs And Outputs

    AMS-AIP can easily be expanded to support another six rooms by adding an AAE Audio Expander. In fact, a total of three AAEs may be added, with simple setup afforded using Crestron Adagio Composer software, supporting up to 24 rooms in all (plus the theater).

  • Page 8: Enhanced Front Panel Control

    Custom naming of rooms, groups, and sources is facilitated on the LCD display, and on the custom label strip using Crestron Engraver software. A selection of pre-made labels is also included.

  • Page 9: Applications

    ), and a combination of up to 12 C2N-DBF12 (12-button keypads) or APAD controllers for local control of each zone. With custom programming (via Adagio Composer, Crestron SystemBuilder™ , or ® SIMPL™ Windows ) and additional AAEs, the AMS-AIP can control up to 25 Media System w/Advanced Image Processing: Adagio AMS-AIP •...

  • Page 10: Specifications

    Media System w/Advanced Image Processing Crestron Adagio AMS-AIP zones of audio. Additional APADs, C2N-DBF12s, CEN-IDOCs and AAS devices can also be added as well as other Crestron peripherals. Specifications Specifications for the AMS-AIP are listed in the following table. AMS-AIP Specifications...
  • Page 11 Dynamic Range (compression) Minimum, Standard, Maximum Frequency Response 20Hz to 20kHz ±0.01dB (preamp), 20Hz to 20kHz ±0.2dB (power amp) (Continued on following page) Media System w/Advanced Image Processing: Adagio AMS-AIP • 7 Operations Guide – DOC. 6516B...
  • Page 12 8-ohm impedance 1600 BTU/hr 4-ohm impedance 2000 BTU/hr Enclosure Black metal with molded ABS/PC front panel; Freestanding, side ventilation should not be restricted (Continued on following page) 8 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 13 The AMS-AIP is designed to work with progressive displays. For optimal image quality, the AMS-AIP should be used with a 1080p display. BTU/hr ratings made while all channels loaded to 1/8 full power with specified impedance. Media System w/Advanced Image Processing: Adagio AMS-AIP • 9 Operations Guide – DOC. 6516B...

  • Page 14: Physical Description

    AMS-AIP Physical View (Rear), Shown with ATC-AMFM2 Adagio AM/FM Dual Tuner Card, ATC-AMFMXM Adagio AM/FM and XM Satellite Radio Tuner Card, and ATC-AMFM2 Adagio AM/FM Dual Tuner Card 10 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 15 (44.61 cm) 18.23 in (46.31 cm) 18.80 in (47.75 cm) NOTE: Cable connections can extend the overall depth of the AMS-AIP by approximately two to three inches. Media System w/Advanced Image Processing: Adagio AMS-AIP • 11 Operations Guide – DOC. 6516B...
  • Page 16 Connectors, Controls, & Indicators CONNECTORS, DESCRIPTION CONTROLS, & INDICATORS SELECTION KNOB Used to select rooms, sources, radio stations (when using tuner), and other parameters. (Continued on following page) 12 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 17 SOFT BUTTONS Function of soft buttons are dependent on operation of AMS-AIP. (Continued on following page) Media System w/Advanced Image Processing: Adagio AMS-AIP • 13 Operations Guide – DOC. 6516B...
  • Page 18 The MUTE button is used to mute or unmute the currently selected room (theater is default). When lit, the selected room is muted. (Continued on following page) 14 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 19 ) video inputs; Input signal sensing on “Y”; Input Level: 1 V nominal (Y), 0.7 V nominal (P Input Impedance: 75 ohms nominal (Continued on following page) Media System w/Advanced Image Processing: Adagio AMS-AIP • 15 Operations Guide – DOC. 6516B...
  • Page 20 HDCP 1.1 protocol HDMI OUTPUT: (1) 19-pin Type A HDMI™ (V.1.3 with Deep Color ） digital video/audio output; includes HDCP 1.1 protocol (Continued on following page) 16 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 21 Allows IR wireless control from Crestron and third-party remotes using RC-5 IR commands. Ring Sleeve Tip: IR Data In Ring: +5 VDC Sleeve: Ground (Continued on following page) Media System w/Advanced Image Processing: Adagio AMS-AIP • 17 Operations Guide – DOC. 6516B...
  • Page 22 Pin 1: CTS Pin 2: GND Pin 3: RXD Pin 4: TXD Pin 5: RTS Pin 6: N/C (Not connected) (Continued on following page) 18 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 23 220-240 VAC, 50-60 Hz, 4 Amps Refer to “Fuse Replacement” on page 38 for additional details. Refer to “Hardware Hookup”, which begins on page 21 for additional cord details. Media System w/Advanced Image Processing: Adagio AMS-AIP • 19 Operations Guide – DOC. 6516B...

  • Page 24: Industry Compliance

    Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. 20 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...

  • Page 25: Setup

    For more details, refer to “Check Network Wiring” on page 115. Hardware Hookup NOTE: Prior to making any connections, refer to the latest version of the Crestron Safety Instructions (Doc. 6607) which can be downloaded from the Crestron website (www.crestron.com/manuals).
  • Page 26 Stereo Theater + Five Stereo Rooms Stereo Theater + Four Stereo Rooms + One Mono Room Stereo Theater + Four Stereo Rooms + Two Mono Rooms 22 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 27 Composer or through the Installer Tools configuration tool. Refer to the Adagio Composer help file or “Configure the Theater” on page 45. NOTE: Connect the subwoofer to the RCA connector or the 3-position terminal block connector. Media System w/Advanced Image Processing: Adagio AMS-AIP • 23 Operations Guide – DOC. 6516B...
  • Page 28 Composer or through the Installer Tools configuration tool. Refer to the Adagio Composer help file or “Configure the Theater” on page 45. NOTE: Connect the subwoofer to the RCA connector or the 3-position terminal block connector. 24 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 29 Composer or through the Installer Tools configuration tool. Refer to the Adagio Composer help file or “Configure the Theater” on page 45. NOTE: Connect the subwoofer to the RCA connector or the 3-position terminal block connector. Media System w/Advanced Image Processing: Adagio AMS-AIP • 25 Operations Guide – DOC. 6516B...
  • Page 30 Composer or through the Installer Tools configuration tool. Refer to the Adagio Composer help file or “Configure the Theater” on page 45. NOTE: Connect the subwoofer to the RCA connector or the 3-position terminal block connector. 26 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 31 Composer or through the Installer Tools configuration tool. Refer to the Adagio Composer help file or “Configure the Theater” on page 45. NOTE: Connect the subwoofer to the RCA connector or the 3-position terminal block connector. Media System w/Advanced Image Processing: Adagio AMS-AIP • 27 Operations Guide – DOC. 6516B...
  • Page 32 Composer or through the Installer Tools configuration tool. Refer to the Adagio Composer help file or “Configure the Theater” on page 45. NOTE: Connect the subwoofer to the RCA connector or the 3-position terminal block connector. 28 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 33 Composer or through the Installer Tools configuration tool. Refer to the Adagio Composer help file or “Configure the Theater” on page 45. NOTE: Connect the subwoofer to the RCA connector or the 3-position terminal block connector. Media System w/Advanced Image Processing: Adagio AMS-AIP • 29 Operations Guide – DOC. 6516B...
  • Page 34 Composer or through the Installer Tools configuration tool. Refer to the Adagio Composer help file or “Configure the Theater” on page 45. NOTE: Connect the subwoofer to the RCA connector or the 3-position terminal block connector. 30 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 35 Composer or through the Installer Tools configuration tool. Refer to the Adagio Composer help file or “Configure the Theater” on page 45. NOTE: Connect the subwoofer to the RCA connector or the 3-position terminal block connector. Media System w/Advanced Image Processing: Adagio AMS-AIP • 31 Operations Guide – DOC. 6516B...
  • Page 36 Out-of-the-box Connections: WARNING: To prevent injury and / or equipment damage due to electric shock, disconnect power from the AMS-AIP prior to making any wiring connections. 32 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 37 C2N-DBF12 devices can be connected. NOTE: The APAD and AMS-AIP front panel are the only control devices that can control the theater room when using the out-of- the box functionality. Media System w/Advanced Image Processing: Adagio AMS-AIP • 33 Operations Guide – DOC. 6516B...
  • Page 38 NOTE: The AAE must be set to its default Net ID value (31). For information on setting the AAE’s Net ID, refer to the latest version of the AAE guide (Doc. 6460) which is available from the Crestron website. Make the connections shown in the following diagram for the AMS-AIP to properly control and switch connected devices while using the out-of-the-box functionality.
  • Page 39 Make the necessary connections as called out in the illustration that follows this paragraph. Refer to “Network Wiring” on page 21 before attaching the 4-position terminal block connectors. Apply power after all connections have been made. Media System w/Advanced Image Processing: Adagio AMS-AIP • 35 Operations Guide – DOC. 6516B...
  • Page 40 AMS-AIP. A microphone jack is also concealed behind the front panel’s label cover. This jack is used to connect the microphone that is included with the available Crestron Professional Surround Sound Tuning Kit. For more information, refer to the latest version of the Crestron Professional Surround Sound Tuning Kit Operations Guide.
  • Page 41 AMS-AIP with Control Devices NOTE: The APAD and AMS-AIP front panel are the only control devices that can control the theater room when using the out-of- the box functionality. Media System w/Advanced Image Processing: Adagio AMS-AIP • 37 Operations Guide – DOC. 6516B...
  • Page 42 AMS-AIP Theater Calibration The speakers in the theater room can be calibrated with the Crestron Professional Surround Sound Tuning Kit to compensate for the interaction of the loudspeaker with the room. For more information, refer to the Crestron Professional Surround Sound Tuning Kit Operations Guide (Doc.
  • Page 43 Labels for Six-Room Distributed Audio Left Right Adagio Composer or Crestron Engraver software can also be used to create and print custom labels on overhead transparency film for the AMS-AIP’s room buttons and function buttons. NOTE: When printing custom labels, some experimentation may be required for optimum results.
  • Page 44 Bend the label strip and position the top of the label strip into the Adagio component. Replace the label cover over the new label s trip. NOTE: Observe proper orientation so the letters are right-side up. 40 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...

  • Page 45: Configuration

    “Select Display Resolution” on page 47 before selecting the on screen display user interface. To activate the selected user interface, press the ENTER button. Media System w/Advanced Image Processing: Adagio AMS-AIP • 41 Operations Guide – DOC. 6516B...
  • Page 46 ⇒ MENU Button – Press the MENU button to return to the previous menu. ⇒ ENTER Button – Press the ENTER button to select a highlighted item or to store a setting. 42 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...

  • Page 47: Installer Tools

    To configure the selected option, press the ENTER button. To exit Installer Tools and save changes to the AMS-AIP’s configuration, press the MENU button. Media System w/Advanced Image Processing: Adagio AMS-AIP • 43 Operations Guide – DOC. 6516B...

  • Page 48: Select Tuner Format

    No to skip the source assignment. A source assignment can be chosen while configuring the theater. Refer to “Configure the Theater” on page 45 for more information. 44 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...

  • Page 49: Configure The Theater

    Select Inputs and press ENTER to open controls for configuring each theater function. • Select Restore Defaults to return the theater configuration to the default settings. Media System w/Advanced Image Processing: Adagio AMS-AIP • 45 Operations Guide – DOC. 6516B...

  • Page 50: Audio Configuration

    Turn the selection knob to select Subwoofer and press the ENTER button to open the Subwoofer control. Subwoofer Control Subwoofer SOURCE SURRND Disabled ROOM THEATER Enabled HOUSE DISPLAY MENU MORE 46 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 51 HOUSE DISPLAY MENU MORE • Turn the selection knob to select the desired resolution setting. To cancel and return to the Configure Theater menu, press MENU. Media System w/Advanced Image Processing: Adagio AMS-AIP • 47 Operations Guide – DOC. 6516B...
  • Page 52 ⇒ Brightness – Adjusts the brightness level of the signal sent to the display. The brightness level is adjustable from 0 to 100 percent. Brightness Control Component 1 SOURCE SURRND Brightness 50% ROOM THEATER HOUSE DISPLAY MENU MORE 48 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 53 Hue Control Component 1 SOURCE SURRND Hue 50% ROOM THEATER HOUSE DISPLAY MENU MORE Turn the selection knob to the desired level and press the ENTER button. Media System w/Advanced Image Processing: Adagio AMS-AIP • 49 Operations Guide – DOC. 6516B...
  • Page 54 Open Installer Tools as described on page 43, select Configure Theater, and press the ENTER button. • Turn the selection knob to select Inputs and press the ENTER button to open the Inputs control. 50 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 55 ⇒ Set the Video Source: Turn the selection knob to select Video and press the ENTER button. The current setting will be bracketed as shown in the following diagram. Media System w/Advanced Image Processing: Adagio AMS-AIP • 51 Operations Guide – DOC. 6516B...
  • Page 56 Once all of the parameters have been set, press the MENU button to return to the list of virtual theater inputs. • Repeat the previous steps for each virtual theater input. 52 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...

  • Page 57: Configure Distributed Audio

    Open Installer Tools as described on page 43, select Configure Distributed Audio, and press the ENTER button. • Turn the selection knob to select Set Number of AMS(-AIP) Rooms, and press the ENTER button. Media System w/Advanced Image Processing: Adagio AMS-AIP • 53 Operations Guide – DOC. 6516B...
  • Page 58 Open Installer Tools as described on page 43, select Configure Distributed Audio, and press the ENTER button. • Turn the selection knob to select Name AMS(-AIP) Rooms, and press the ENTER button. 54 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 59 Open Installer Tools as described on page 43, select Configure Distributed Audio, and press the ENTER button. • Turn the selection knob to select Name AAE Rooms, and press the ENTER button. Media System w/Advanced Image Processing: Adagio AMS-AIP • 55 Operations Guide – DOC. 6516B...
  • Page 60 Open Installer Tools as described on page 43, select Configure Distributed Audio, and press the ENTER button. • Turn the selection knob to select Set AAE Theater Source, and press the ENTER button. 56 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 61 ENTER. • To enter a custom name, turn the selection knob until [Custom Name] is displayed and press ENTER. Media System w/Advanced Image Processing: Adagio AMS-AIP • 57 Operations Guide – DOC. 6516B...
  • Page 62 Show. After all of the sources to be shown are designated as such, press MENU to return to the Distributed Audio menu. 58 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 63 LCD. If a button is not to be used, select Not Used. • After selecting the source, press the ENTER button to save the assignment and return to the list of buttons. Media System w/Advanced Image Processing: Adagio AMS-AIP • 59 Operations Guide – DOC. 6516B...

  • Page 64: Identify Keypads

    NOTE: When using the out-of-the-box functionality, the theater room can only use an APAD or the front panel for control as shown in the following diagram. 60 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 65 Repeat the procedure until control devices for all of the specified rooms (refer to page 53) have been identified. • Press MENU to return to the Installer Tools menu. Media System w/Advanced Image Processing: Adagio AMS-AIP • 61 Operations Guide – DOC. 6516B...

  • Page 66: Load Apads

    MORE • Turn the selection knob to select System Information or HDMI/DVI Information and press ENTER. • Press MENU to return to the Installer Tools menu. 62 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 67 < > • Press the soft buttons labeled < or > to display information about the connection. • Press MENU to return to the About menu. Media System w/Advanced Image Processing: Adagio AMS-AIP • 63 Operations Guide – DOC. 6516B...

  • Page 68: Configure Sources

    Room 3 SOURCE SURRND Select Parameter ROOM THEATER to Adjust HOUSE DISPLAY MinV MaxV StartV Mono MENU MORE Parameters that can be adjusted include: ⇒ Minimum Volume 64 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 69 The lowest maximum volume setting is 70%. Press the soft button labeled Reset to set the volume level to 100%. Media System w/Advanced Image Processing: Adagio AMS-AIP • 65 Operations Guide – DOC. 6516B...
  • Page 70 Stereo to select the Stereo mode. Press the soft button labeled Mono to select the Mono mode. NOTE: Other rooms can be adjusted by pressing a different room button. 66 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...

  • Page 71: Configure Theater

    The highest minimum volume setting is 50%. Press the soft button labeled Reset to set the volume level to 20%. • Press MENU to return to the Theater Setup menu. Media System w/Advanced Image Processing: Adagio AMS-AIP • 67 Operations Guide – DOC. 6516B...

  • Page 72: Configure Preset Groups

    Edit a Preset Group To edit a preset group: • Press the ROOM button to enter the Room mode. 68 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 73 Move the cursor to another position by pressing the soft buttons labeled . To delete a character, press the soft button labeled Del. NOTE: The maximum length for any preset group name is 16 characters. Media System w/Advanced Image Processing: Adagio AMS-AIP • 69 Operations Guide – DOC. 6516B...
  • Page 74 Theater. • After editing the preset group, press Done to save the changes and return to the Groups listing. 70 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...

  • Page 75: Operation

    Source Bklt • To select a source, turn the selection knob until the desired source is displayed on the front panel and press the ENTER button. Media System w/Advanced Image Processing: Adagio AMS-AIP • 71 Operations Guide – DOC. 6516B...
  • Page 76 The signal is steered to the rear speakers. ⇒ Multi-Channel Stereo – Steers the left and right audio signals to all of the theater speakers. 72 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...

  • Page 77: Theater Mode

    The backlighting level of the display and buttons can be set when operating in the Theater mode. The display can also be set to automatically dim the display to the lowest setting after approximately 30 seconds of inactivity. Media System w/Advanced Image Processing: Adagio AMS-AIP • 73 Operations Guide – DOC. 6516B...
  • Page 78 MORE button again. Additional Theater Controls Theater SOURCE SURRND No Source Selected ROOM Multi-Channel Analog THEATER HOUSE DISPLAY MENU MORE Tools Groups Sleep 74 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 79 Flat to set the treble level to 0dB. ⇒ Audssy – Enables or disables Audyssey processing. For information on configuring Audyssey, refer to “Configuring the AMS-AIP” on page 110. Media System w/Advanced Image Processing: Adagio AMS-AIP • 75 Operations Guide – DOC. 6516B...
  • Page 80 Press the soft button labeled Sleep to open the Sleep controls. Sleep Controls Theater SOURCE SURRND Sleep Timer ROOM THEATER 0:00 HOUSE DISPLAY MENU MORE Adjust 76 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 81 ⇒ On – Press the soft button labeled On to start the sleep timer. ⇒ Off – Press the soft button labeled Off to stop the sleep timer. Media System w/Advanced Image Processing: Adagio AMS-AIP • 77 Operations Guide – DOC. 6516B...

  • Page 82: Source Mode

    The frequency/channel and other information will be displayed. FM Radio Source S1 AM/FM SOURCE SURRND 101.90 FM ROOM THEATER Stereo HOUSE DISPLAY MENU MORE Control 78 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 83 (AM or FM). AM/FM Controls 101.90 FM Stereo SOURCE SURRND ROOM THEATER S1 AM/FM HOUSE DISPLAY MENU MORE Preset Manual Tech Media System w/Advanced Image Processing: Adagio AMS-AIP • 79 Operations Guide – DOC. 6516B...
  • Page 84 SURRND 100.50 FM ROOM THEATER HOUSE DISPLAY MENU MORE Cancel Press the soft button labeled OK to confirm or the soft button labeled Cancel to cancel. 80 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 85 SURRND FM Signal Strength: 75% ROOM THEATER HOUSE DISPLAY S1 AM/FM MENU MORE Stereo Mono ⇒ To return to the tuner controls, press the MENU button. Media System w/Advanced Image Processing: Adagio AMS-AIP • 81 Operations Guide – DOC. 6516B...
  • Page 86 6. The 60s 8. The 80s HOUSE DISPLAY MENU MORE Save Select a preset location with the selection knob and press the soft button labeled Save. 82 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 87 1. XM Preview ROOM THEATER 4. The 40s 5. The 50s HOUSE DISPLAY MENU MORE ⇒ Turn the selection knob to view the list of available channels. Media System w/Advanced Image Processing: Adagio AMS-AIP • 83 Operations Guide – DOC. 6516B...
  • Page 88 Press the MENU button to return to the XM Technical Information controls. ⇒ To hide or unhide channels from the channel listing: Press the soft button labeled Setup. The list of channels will be displayed. 84 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 89 SIRIUS Radio Controls Elvis Radio SOURCE SURRND Elvis Presley ROOM THEATER All Shook Up HOUSE S1 SIRIUS DISPLAY MENU MORE Preset Chan Tech Media System w/Advanced Image Processing: Adagio AMS-AIP • 85 Operations Guide – DOC. 6516B...
  • Page 90 Press the soft button labeled Preset. Preset Controls Presets SOURCE SURRND 12. Super Shuffle ROOM THEATER 6. `60s Vibrations 8. Big `80s HOUSE DISPLAY MENU MORE Clear Save 86 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 91 ⇒ Turn the selection knob to view the list of available categories. ⇒ Press the ENTER button to select a category. ⇒ Turn the selection knob to view the list of channels in the category. Media System w/Advanced Image Processing: Adagio AMS-AIP • 87 Operations Guide – DOC. 6516B...
  • Page 92 “Technical Section” on page 89. NOTE: Channel 0 displays the radio ID which is required for subscription to the SIRIUS radio service. 88 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 93 Radio ID: 012345678901 HOUSE DISPLAY S1 SIRIUS MENU MORE About Setup ⇒ To view firmware and other information about the tuner card: Press the soft button labeled About. Media System w/Advanced Image Processing: Adagio AMS-AIP • 89 Operations Guide – DOC. 6516B...
  • Page 94 Turn the selection knob clockwise or counterclockwise to highlight Setup Channels and press the ENTER button to display a list of all of the SIRIUS channels. 90 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 95 Turn the selection knob clockwise or counterclockwise to highlight Setup Channels and press the ENTER button to display a list of all of the SIRIUS channels. Media System w/Advanced Image Processing: Adagio AMS-AIP • 91 Operations Guide – DOC. 6516B...
  • Page 96 HOUSE DISPLAY MENU MORE Turn the selection knob clockwise or counterclockwise to highlight Change PIN and press the ENTER button to display the Change PIN controls. 92 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...

  • Page 97: Controlling An Ipod Or Iphone

    Source Source 5 SOURCE SURRND Oh, Pretty Woman ROOM THEATER Roy Orbison HOUSE DISPLAY MENU MORE Control Media System w/Advanced Image Processing: Adagio AMS-AIP • 93 Operations Guide – DOC. 6516B...
  • Page 98 All – Will shuffle all items in the list. Album – Will play the songs on an album in order and then shuffle the order of the albums. 94 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 99 Bottom. If a song name is selected, pressing the ENTER button will begin playback. Playlist Items My Favorites SOURCE SURRND As Tears Go By ROOM THEATER Baba O’Riley HOUSE DISPLAY MENU MORE Back Bottom Media System w/Advanced Image Processing: Adagio AMS-AIP • 95 Operations Guide – DOC. 6516B...

  • Page 100: Controlling An Adagio Audio Server (Aas)

    Press the MORE button to display soft buttons to change the Shuffle and Repeat modes and manage the playback queue. Press the MORE button again to return to the playback controls. 96 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 101 Off – Plays all queued items once without repeat. Song – Will repeat the song that is currently playing. Queue – Will repeat all of the songs in the play queue. Media System w/Advanced Image Processing: Adagio AMS-AIP • 97 Operations Guide – DOC. 6516B...
  • Page 102 Press the soft button labeled Back to erase the previous character and move the cursor back one space. Press the soft button labeled Done to save the p laylist name. 98 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 103 MORE button, then press the soft button labeled Down. ⇒ Pres s the MENU button to return to the playback contro Media System w/Advanced Image Processing: Adagio AMS-AIP • 99 Operations Guide – DOC. 6516B...
  • Page 104 If a group (Genre or All Songs) or an individual song is highlighted, press the ENTER button to choose between playing the highlighted selection (thereby replacing the queue) or adding the selected item to the current queue. 100 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 105 ROOM THEATER ABCDEFGHIJKLM HOUSE DISPLAY NOPQRSTUVWXYZ MENU MORE ⇒ Select a letter with the selection knob and press the ENTER button. Media System w/Advanced Image Processing: Adagio AMS-AIP • 101 Operations Guide – DOC. 6516B...

  • Page 106: Route A Source

    MORE button. • To turn on the room, press the soft button labeled On. • To turn off the room, press the soft button labeled Off. 102 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 107 MORE Adjust To set the amount of sleep time, press the soft button labeled Adjust. The sleep time is adjustable from 1 minute to 6 hours. Media System w/Advanced Image Processing: Adagio AMS-AIP • 103 Operations Guide – DOC. 6516B...
  • Page 108 While in Room mode, press the MORE button. • Press the soft button labeled Tools. • Press the soft button labeled Treble to open the Treble control. 104 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...
  • Page 109 While in Room mode, press the MORE button. • Press the soft button labeled Tools. • Press the soft button labeled Loud to open the Loudness control. Media System w/Advanced Image Processing: Adagio AMS-AIP • 105 Operations Guide – DOC. 6516B...

  • Page 110: Party Mode And Other Room Groups

    The front panel controls can be locked by pressing the MENU and DISPLAY buttons simultaneously for five seconds. The front panel controls can be unlocked by pressing the MENU and DISPLAY buttons simultaneously for five seconds. 106 • Media System w/Advanced Image Processing: Adagio AMS-AIP Operations Guide – DOC. 6516B...

  • Page 111: Turn Off The Theater

    Press THEATER OFF to turn off the theater outputs. The room outputs will stay Turn off the System Press All Off to turn off all of the rooms and the theater. Media System w/Advanced Image Processing: Adagio AMS-AIP • 107 Operations Guide – DOC. 6516B...

  • Page 112: Programming Software

    Have a question or comment about Crestron software? Answers to frequently asked questions (FAQs) can be viewed in the Online Help section of the Crestron website. To post a question or view questions you have submitted to Crestron’s True Blue Support, log in at http://support.crestron.com.

  • Page 113: Programming With Simpl Windows

    NOTE: When programming an AMS-AIP in SIMPL Windows, always begin with the example program and modify as required. To find example programs, refer to “Example Program” on page 110. Also visit Crestron’s True Blue Support on the web for more programming tips.

  • Page 114: Configuring The Ams-Aip

    AMS-AIP program need to be updated. To save settings for later use, use the Crestron Toolbox File Manager utility to retrieve the *.xml (where * can be “ootbf” for settings made when running the out- of-the-box functionality program or “custom”...

  • Page 115: Uploading And Upgrading

    PC via the included serial cable (Crestron STCP-502PC or equivalent). • Use the Address Book in Crestron Toolbox to create an entry using the expected serial communication protocol (RS232, auto-detect baud rate, no parity, 8 data bits, 1 stop bit, XON/XOFF disabled, RTS/CTS enabled).

  • Page 116: Programs And Firmware

    The USB port on the AMS-AIP connects to the USB port on the PC via the included USB cable. • Use the Address Book in Crestron Toolbox to create an entry using the expected communication protocol (USB). When multiple USB devices are connected, identify the AMS-AIP by entering “AMS-AIP” in the Model textbox, the unit’s serial number in the Serial textbox or the unit’s hostname...
  • Page 117 SIMPL Windows or Crestron Toolbox. Firmware Check the Crestron website to find the latest firmware. (New users may be required to register to obtain access to certain areas of the site, including the FTP site.) Upgrade AMS-AIP firmware via Crestron Toolbox.

  • Page 118: Problem Solving

    Media System w/Advanced Image Processing Crestron Adagio AMS-AIP Problem Solving Troubleshooting The following table provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. AMS-AIP Troubleshooting TROUBLE POSSIBLE CAUSE(S) CORRECTIVE ACTION...

  • Page 119: Check Network Wiring

    Cresnet power usage of the entire chain. If the unit is home-run from a Crestron system power supply network port, the Cresnet power usage of that unit is the Cresnet power usage of the entire run. The wire gauge and the Cresnet power usage of the run should be used in the following equation to calculate the cable length value on the equation’s left side.

  • Page 120: Reference Documents

    Make sure the cable length value is less than the value calculated on the right side of the equation. For example, a Cresnet run using 18 AWG Crestron Certified Wire and drawing 20 watts should not have a length of run more than 333 feet. If Cresnet HP is used for the same run, its length could extend to 1250 feet.

  • Page 121: Future Updates

    First-time users will need to establish a user account to fully benefit from all available features. Future Updates As Crestron improves functions, adds new features, and extends the capabilities of the AMS-AIP, additional information may be made available as manual updates. These updates are solely electronic and serve as intermediary supplements prior to the release of a complete technical documentation revision.

  • Page 122: Software License Agreement

    This Agreement may only be modified by a writing signed by an authorized officer of Crestron. Updates may be licensed to You by Crestron with additional or different terms. This is the entire agreement between Crestron and You relating to the Software and it supersedes any prior representations, discussions, undertakings, communications or advertising relating to the Software.
  • Page 123 “applets” incorporated into the Software), the accompanying media and printed materials and any copies of the Software are owned by Crestron or its suppliers. The Software is protected by copyright laws and international treaty provisions. Therefore, you must treat the Software like any other copyrighted material, subject to the provisions of this Agreement.

  • Page 124: Return And Warranty Policies

    Purchasers should inquire of the dealer regarding the nature and extent of the dealer's warranty, if any. CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures.

  • Page 125: Trademark Information

    Audyssey MultEQ XTis a trademark of Audyssey Laboratories. VXP, Visual Excellence Processing, TruMotionHD, Reality Expansion, FidelityEngine, FineEdge, and the VXP Logo are trademarks or registered trademarks of Gennum Corporation. Media System w/Advanced Image Processing: Adagio AMS-AIP • 121 Operations Guide – DOC. 6516B...
  • Page 126 Crestron Electronics, Inc. Operations Guide – DOC. 6516B 15 Volvo Drive Rockleigh, NJ 07647 (2015970) Tel: 888.CRESTRON 10.08 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
