Crestron Adagio AMS-AIP Operation Manual page 11

®
Crestron Adagio
Operations Guide – DOC. 6516B
AMS-AIP Media System w/Advanced Image Processing
AMS-AIP Specifications (Continued)
SPECIFICATION
Video (continued)
Output Aspect Ratios
Analog Gain
Analog Bandwidth
Analog Crosstalk
Analog Signal to Noise Ratio
(SNR)
Audio – Surround Sound
Processor
Processor
Analog-To-Digital Conversion
Digital-To-Analog Conversion
Supported Formats/Modes
Surround Sound Master Volume
Speaker Compensation
Low Frequency Effects (LFE)
Mode Trim (Level Preset)
Input Compensation
Mute
Bass Gain Range
Treble Gain Range
EQ Modes
PEQ Filter Gain
PEQ Filter Bandwidth
PEQ Filter Center Frequency
GEQ Filter Gain
GEQ Filter Center Freq.
Crossover/High-Pass Freq.
Maximum Delay
Dynamic Range (compression)
Frequency Response
(Continued on following page)
Media System w/Advanced Image Processing: Adagio AMS-AIP • 7
DETAILS
4:3, 5:4, 15:9, or 16:9 based on resolution
0dB (75 ohms terminated)
400 MHz
> 54dB
> 70dB
Texas Instruments DA610 Aureus™ 32-bit
floating point DSP w/Audysey MultEQ
setup algorithms
24-bit 48 kHz
24-bit 48 kHz
Bypass, Stereo, 2-channel steering
(surround or rear), Multi-channel stereo,
Ambience Effects (Cathedral, Hall, Stadium,
®
Jazz Club), Dolby Pro Logic IIx, Dolby
Digital 5.1, Dolby Digital EX, DTS Neo:6,
DTS Digital 5.1 Discrete, DTS ES 6.1
Discrete, DTS ES 6.1 Matrix, DTS 96/24
-80dB to +20dB, 0.5dB steps
±12dB, 0.5dB steps
-10dB to +0dB, 0.5dB steps
±12dB, 0.5dB steps (master); ±12dB, 0.5dB
steps (per output); -10dB to +0dB, 0.5dB
steps (LFE)
±10dB, 1dB steps
-80dB (electronic), >-100dB (relay)
±12dB, 1dB steps
±12dB, 1dB steps
Audyssey MultEQ XT or 6-band parametric
or graphic per surround/subwoofer output
channel
±12dB, 0.5dB steps
0.02 to 2.0 octaves
20Hz to 20KHz
±10dB, 0.5dB steps
50, 180, 630, 2.3k, 8k Hz
40 to 200 Hz, 10 Hz steps
80ms per channel, picture delay (lip-sync)
and speaker distance compensation
combined
Minimum, Standard, Maximum
20Hz to 20kHz ±0.01dB (preamp),
20Hz to 20kHz ±0.2dB (power amp)
®
XT
